Airtac X-KCV Basic Type Vacuum Generator X-KCV05HS
$16.04
Regular price
$23.54
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-KCV05HS
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-KCV Basic Series Vacuum Generator X-KCV05HS Technical Details
- Model: X-KCV05HS
- Type: Compact single-stage vacuum generator
- Vacuum flow rate: 30 L/min @ 0.5MPa
- Maximum vacuum level: -84kPa (-630mmHg)
- Air consumption: 25 L/min @ 0.5MPa
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.25–0.7 MPa
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: 5℃ to 60℃ (no icing)
- Noise level: ≤72 dB(A)
- Weight: 180g ±5%
- Dimensions: 55mm(L) × 45mm(W) × 72mm(H)
- Thread depth: 10mm (suction port)
- Response time: ≤0.3s (vacuum establishment)
High-efficiency vacuum generation unit featuring integrated silencer and vacuum switch port. Engineered with turbulence-reduction channels for stable suction performance, compatible with ISO 5599-1 mounting standards. Requires 5μm filtered compressed air (40% relative humidity max).
Industrial Applications:
- PCB handling in SMT production lines
- Plastic cap sorting in pharmaceutical packaging
- Glass panel positioning for display assembly
- Automated wafer handling in semiconductor FOUPs
- Paper sheet separation in printing machinery
Operation tip:
Maintain 1.5-2x port diameter straight piping upstream. For intermittent use,
allow 2-second purge cycle between operations. Maximum duty cycle: 90% @ 0.5MPa.
| Property | Property Value |
|---|---|
| sku | X-KCV05HS |
