AirTAC X-KCV Basic Series Vacuum Generator X-KCV10HS Technical Details
- Model: X-KCV10HS (High-Speed variant)
- Vacuum flow rate: 30 L/min @ 0.5 MPa
- Operating pressure range: 0.25–0.7 MPa
- Maximum vacuum level: -88 kPa (-660 mmHg)
- Response time: ≤0.1 sec (vacuum build-up)
- Port size: M5 (G1/8 adapter optional)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Operating temperature: -10℃ to 60℃
- Weight: 185g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 42mm(H)
- Air consumption: 11 NL/min @ 0.5 MPa
- Sound level: ≤65 dB(A)
- Mounting: 2× M4 threaded holes (6mm depth)
Compact ejector-type vacuum generator optimized for rapid pick-and-place operations. Features integrated silencer and shock-resistant structure with anti-vibration pads. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size). Compatible with vacuum cups up to φ16mm.
Industrial Applications:
- PCB handling in SMT assembly lines
- Plastic injection molding part extraction
- Pharmaceutical blister packaging systems
- Glass panel transfer robots
- Automotive component testing fixtures
Installation protocol:
Maintain minimum 300mm tubing length between generator and vacuum cup.
Use air lubricator (ISO VG32 oil) when continuous operation exceeds 2 hours.
Monthly maintenance: Clean filter screen with ultrasonic bath (40kHz, 5min).
