Airtac X-KCV Basic Type Vacuum Generator X-KCV10LS
AirTAC X-KCV Basic Series Vacuum Generator X-KCV10LS Specifications
- Model: X-KCV10LS
- Type: Single-stage ejector with integrated silencer
- Vacuum flow rate: 10 L/min @ 0.5 MPa
- Maximum vacuum level: -92 kPa (approx. 27 inHg)
- Air consumption: 25 L/min @ 0.5 MPa
- Operating pressure range: 0.25–0.7 MPa
- Port sizes: 1/8" NPT (M5 & PT1/8 adapters available)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: 5℃ to 60℃ (non-freezing)
- Weight: 0.23 kg (0.51 lbs)
- Dimensions: 46mm(L) × 32mm(W) × 62mm(H)
- Sound pressure level: ≤65 dB(A)
- Response time: ≤0.3 sec (vacuum generation)
- Thread depth: 10mm (for workpiece connection)
Compact vacuum generator optimized for rapid pick-and-place operations, featuring energy-efficient vortex flow design. The integrated muffler reduces operational noise while maintaining stable suction performance. Self-compensating design maintains vacuum level under minor leakage conditions.
- PCB handling in electronics assembly lines
- Plastic cap positioning in pharmaceutical packaging
- Glass panel transfer for display manufacturing
- Paper sheet separation in printing machinery
- Small part fixturing during precision machining
Installation note:
Always install upstream 5μm filter. Optimal performance achieved when mounted
within 2 meters of vacuum cup. For continuous operation, implement 10-minute
rest cycles every 2 hours during initial 50-hour break-in period.
| Property | Property Value |
|---|---|
| sku | X-KCV10LS |
