Airtac X-KCV Basic Type Vacuum Generator X-KCV10LSCK
AirTAC X-KCV10LSCK Basic Vacuum Generator Technical Specifications
- Model: X-KCV10LSCK
- Type: Single-stage ejector with built-in silencer
- Port size: M5 (1/8") threaded connections
- Operating pressure range: 0.3-0.7 MPa
- Air consumption: 0.8-1.2 L/min (ANR)
- Vacuum flow rate: 30 L/min (at -50kPa)
- Max vacuum level: -85 kPa (-638 mmHg)
- Response time: ≤0.1 sec (vacuum generation)
- Weight: 0.28 kg
- Dimensions: 60mm(L) × 30mm(W) × 25mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (optional FKM available)
- Operating temperature: -10℃ to 60℃
- Noise level: ≤55 dB(A) with integrated muffler
- Proof pressure: 1.05 MPa
Compact vacuum generator optimized for high-speed pick-and-place operations, featuring rapid vacuum generation and collapse characteristics. The integrated silencer design reduces operational noise while maintaining airflow efficiency. Precision-machined nozzle ensures consistent vacuum performance with 40μm filtered air supply.
- PCB component handling systems
- Automated packaging line suction cups
- Medical device assembly stations
- Semiconductor wafer handling
- Robotic end-effector vacuum systems
Installation note:
Maintain horizontal mounting position for optimal particle drainage.
Use 5-10mm ID vacuum tubing and ensure exhaust port remains unobstructed.
Regular cleaning of filter element (every 500 operating hours) recommended.
| Property | Property Value |
|---|---|
| sku | X-KCV10LSCK |
