AirTAC X-KCV15HS Basic Series Vacuum Generator Technical Details
- Model: X-KCV15HS (Basic Type)
- Type: Single-stage ejector with integrated silencer
- Vacuum flow rate: 15 L/min @ 0.5MPa
- Maximum vacuum level: -88kPa (relative pressure)
- Operating pressure range: 0.25–0.7 MPa
- Air consumption: 25 L/min @ 0.5MPa
- Port size: M5 (supply)/φ4.5mm (vacuum port)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: 5℃ to 60℃ (no freezing)
- Weight: 320g ±5%
- Dimensions: 80mm(L) × 35mm(W) × 45mm(H)
- Sound pressure level: ≤65 dB(A)
- Response time: 0.15s (vacuum build-up to -70kPa)
Compact vacuum generator optimized for rapid pick-and-place operations, featuring an integrated muffler for noise reduction. The anti-corrosion aluminum body ensures durability in humid environments. Requires clean compressed air (ISO 8573-1:2010 Class 3-4-3) with 5-40μm filtration.
Industrial Applications:
- PCB handling in electronics assembly lines
- Plastic part transfer systems in injection molding
- Paper feeding mechanisms in printing equipment
- Medical device packaging automation
- Glass panel manipulation in solar panel production
Installation guidelines:
Maintain horizontal mounting orientation for optimal particle drainage.
Use flexible tubing (ID ≥4mm) with maximum 2m length between generator
and suction cup. Perform weekly exhaust port cleaning in dusty environments.
Performance tip: Achieve 20% faster cycle times by pairing
with AirTAC VCHD15 vacuum cup and maintaining 0.45-0.55MPa supply pressure.
