Airtac X-KCV Basic Type Vacuum Generator X-KCV15LS
AirTAC X-KCV15LS Basic Series Vacuum Generator Technical Details
- Model: X-KCV15LS
- Type: Single-stage vacuum generator with integrated silencer
- Vacuum flow rate: 15 L/min @ 0.5MPa
- Maximum vacuum level: -88kPa (typical)
- Operating pressure range: 0.25–0.7 MPa
- Air consumption: 4.2 NL/min @ 0.5MPa
- Port size: M5 (1/8") threaded connections
- Body material: Anodized aluminum alloy
- Gasket material: NBR (Nitrile rubber)
- Operating temperature: 5℃ to 60℃
- Weight: 78g ±2g
- Dimensions: 42mm(W) × 25mm(H) × 98mm(L)
- Noise level: ≤68 dB(A)
- Response time: <0.15s vacuum build-up
- Compatible tubing ID: Φ4mm (standard)
The X-KCV15LS features optimized flow path geometry for rapid vacuum generation with 30% reduced air consumption compared to previous models. Its asymmetric structure prevents particle accumulation, while the sintered aluminum silencer ensures quiet operation. Requires clean compressed air (ISO 8573-1:2010 Class 3.4.2) with 5-40μm filtration.
- PCB handling in SMT assembly lines
- Plastic part positioning in injection molding machines
- Glass panel transfer systems for display manufacturing
- Medical device packaging automation
- Small part sorting in robotic pick-and-place units
Installation guidelines:
Mount vertically with vacuum port facing downward. Maintain minimum 50mm
clearance from adjacent components for optimal airflow. Use vibration-absorbing
mounts in high-cycle applications (>2Hz). Regular maintenance interval:
5,000 operating hours or 6 months.
| Property | Property Value |
|---|---|
| sku | X-KCV15LS |
