AirTAC X-KCV20HS Basic Vacuum Generator Technical Details
- Model: X-KCV20HS (Basic Series)
- Vacuum Level: -88kPa (max)
- Air Consumption: 105 NL/min @ 0.5MPa
- Operating Pressure Range: 0.25–0.7 MPa
- Flow Rate: 185 L/min
- Port Size: Rc1/8 (BSPP 1/8")
- Body Material: Anodized aluminum alloy
- Seal Material: NBR (Nitrile rubber)
- Temperature Range: 5℃ to 60℃
- Weight: 290g ±5g
- Dimensions: 93mm(L) × 34mm(W) × 44mm(H)
- Sound Level: ≤70 dB(A)
- Response Time: 0.1s (vacuum build-up)
- Mounting: 2x M4 threaded holes (8mm depth)
Compact ejector-style vacuum generator featuring energy-efficient design with built-in silencer. Optimized for rapid vacuum creation and release cycles, with corrosion-resistant construction for industrial environments. Requires ISO 8573-1:2010 Class 4 compressed air (40μm filtration).
Common Applications:
- PCB handling in SMT assembly lines
- Plastic part positioning in injection molding
- Glass panel transfer systems
- Automated packaging machine pick-and-place
- Medical device assembly vacuum chucks
Installation tip:
Maintain minimum 300mm distance from electromagnetic interference sources.
Use anti-vibration pads when mounting on surfaces exceeding 0.5G vibration acceleration.
Service Requirements:
Lubricate moving parts every 5 million cycles using ISO VG32 turbine oil.
Replace NBR seals annually in continuous operation environments.
