Airtac X-KCV Basic Type Vacuum Generator X-KCV25HS
AirTAC X-KCV25HS Basic Series Vacuum Generator Technical Specifications
- Model: X-KCV25HS
- Type: Single-stage ejector with integrated silencer
- Vacuum flow rate: 25 L/min @ 0.5MPa
- Maximum vacuum level: -88kPa (-660mmHg)
- Compressed air consumption: 95 L/min @ 0.5MPa
- Supply port size: Rc1/8 (G1/8 equivalent)
- Vacuum port size: Φ4.5mm push-in fitting
- Operating pressure range: 0.2–0.7 MPa
- Body material: Anodized aluminum alloy
- Internal components: Stainless steel
- Temperature range: 5℃ to 60℃ (no freeze)
- Noise level: ≤65 dB(A)
- Vacuum repeat accuracy: ±2% F.S.
- Response time: ≤0.3s (vacuum establishment)
- Weight: 180g ±5g
- Dimensions: 78mm(L) × 32mm(W) × 40mm(H)
- Protection rating: IP40
The X-KCV25HS features optimized nozzle geometry for energy-efficient vacuum generation, achieving 15% lower air consumption than previous models. Its shock-resistant design maintains stable vacuum levels even under pulsating air supply conditions. The built-in muffler reduces exhaust noise while preventing debris ingress.
- PCB handling in SMT production lines
- Plastic part retention in injection molding automation
- Glass panel positioning for display manufacturing
- Carton sealing systems in packaging machinery
- Medical device assembly stations
Installation guidelines:
Maintain horizontal mounting orientation for optimal particle drainage.
Use ISO 8573-1 Class 3.4.2 compressed air (max 5μm/0.1mg/m³).
Replace internal filter element every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | X-KCV25HS |
