Airtac X-KCV Basic Type Vacuum Generator X-KCV25LS
AirTAC X-KCV25LS Basic Series Vacuum Generator Technical Details
- Model: X-KCV25LS
- Type: Compact single-stage vacuum generator
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.1-0.7 MPa
- Max vacuum level: ≥-80kPa (-600mmHg)
- Air consumption: ~25 L/min @0.5MPa
- Flow rate: 140 L/min (F.R. when vacuum broken)
- Body material: Anodized aluminum alloy
- Seal material: NBR rubber
- Temperature range: -10℃ to 60℃
- Weight: 0.45kg ±3%
- Dimensions: 80mm(L) × 35mm(W) × 35mm(H)
- Noise level: ≤72 dB(A)
- Response time: <0.3s (vacuum establishment)
Compact vacuum generator featuring high suction efficiency with low air consumption. Integrated silencer reduces operational noise by 15% compared to previous models. Optimized flow path design enables quick vacuum formation (reaches -60kPa in 0.15s). Built-in check valve prevents backflow during power loss.
- PCB handling in SMT assembly lines
- Plastic part gripping in injection molding machines
- Glass panel transfer systems
- Medical device packaging automation
- Carton box sealing systems
Installation guidelines:
Mount within 1m of vacuum cup for optimal performance. Use 5μm filtered
dry air supply (pressure dew point ≤3℃). Regular maintenance: Clean
exhaust filter every 500 operating hours using compressed air blowback.
| Property | Property Value |
|---|---|
| sku | X-KCV25LS |
