Airtac X-KCV Basic Type Vacuum Generator X-KCV30HS
AirTAC X-KCV30HS Basic Vacuum Generator Technical Details
- Model: X-KCV30HS (Basic Series)
- Vacuum Flow Rate: 30 L/min @ 0.5 MPa
- Maximum Vacuum Level: -88 kPa (atmospheric pressure basis)
- Operating Pressure Range: 0.25–0.7 MPa
- Air Consumption: 15.5 NL/min @ 0.5 MPa
- Port Size: M5 (Rc1/8 optional)
- Body Material: Anodized aluminum alloy
- Seal Material: NBR (Nitrile rubber)
- Temperature Range: 0℃ to 60℃
- Response Time: ≤0.3 sec (vacuum generation)
- Noise Level: ≤72 dB(A)
- Weight: 230 g ±5%
- Dimensions: 84mm(L) × 36mm(W) × 55mm(H)
- Mounting: Direct pipeline connection with M5 threads
- Protection Class: IP40 (standard configuration)
Compact ejector-type vacuum generator optimized for rapid pick-and-place operations. Features integrated silencer and maintenance-free operation with energy-efficient flow design. Requires clean compressed air (40μm filtration recommended) and performs best with intermittent duty cycles. Built-in vacuum port allows direct suction cup connection.
- PCB handling in electronics assembly lines
- Plastic part retention in injection molding machines
- Paper sheet separation in printing/copying equipment
- Medical device component positioning systems
- Small part sorting in automated packaging machinery
Operational Guidance:
Maintain air supply pressure stability (±10% of rated pressure) for consistent performance.
Install downstream filter regulator with auto-drain function. Maximum continuous operation
duration should not exceed 90 seconds without 30-second cooling interval.
- Vacuum switch ready (VS-X series compatible)
- Multiple unit parallel installation supported
- Available with built-in check valve (X-KCV30HS-CV variant)
| Property | Property Value |
|---|---|
| sku | X-KCV30HS |
