This model is discontinued
AirTAC has phased out the MALD series. You can still order this code here: we ship the direct replacement MBLD20X100-LB, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLD replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB
The AirTAC Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB is a double-acting, double-rod aluminum mini cylinder: a rod exits both ends of the Ø20mm bore, so push and pull force are equal. This model is discontinued — the direct replacement is the MBLD20X100-LB, matching bore, stroke, force and mounting.
- BoreØ20 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod
- Rod threadM8×1.25
- StatusDiscontinued → MBLD20X100-LB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB
The AirTAC MALD20X100-LB is a discontinued double-acting, double-rod miniature cylinder. A rod exits both ends of the 20 mm bore, yielding exactly 132 N of force in both push and pull directions at 0.5 MPa. The direct replacement is the MBLD20X100-LB, matching the 100 mm stroke, G1/8 port, and LB foot mounting.
This SKU has no magnet and cannot accept a position sensor. It uses a fixed rubber bumper rather than an adjustable cushion. The original MALD features threaded covers and a heterogeneous grease-retaining seal, whereas the MBLD upgrade uses a riveted rolling-packed body. The twin carbon-steel rods are hard-chrome plated to resist wear and double the bearing area for guided sliding.
Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB Technical Specifications
| Model | Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB |
|---|---|
| Series | MALD double-rod mini cylinder (discontinued) |
| Replacement | MBLD20X100-LB |
| Bore size | Ø20 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
Double-rod types have no back-cover code and no SDB pivot; mount on the body, LB foot or FA flange. The MBLD20X100-LB carries the same ratings.
Output Force — Equal Both Ways (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | 185 N |
| Max (@1.0 MPa) | 27 kgf | |
A rod exits both ends, so the effective area — and force — is equal in both directions. The MBLD20X100-LB matches these values.
Model Code: Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB
| MALD | Double-rod aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×100 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLD uses CMSG/DMSG/EMSG). |
Replacement: MALD → MBLD. No back-cover (CA/U/CM) and no SDB on double-rod. Mounting: LB / FA.
Where the Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB Is Used
PCB Depaneling Saw
Drives a synchronized cutting blade carriage where the twin 8 mm rods prevent yaw. The 132 N equal force ensures clean cuts in both directions without rotational drift.
Pick-and-Place Transfer
Moves small electronic caps between belts. The rear rod acts as a stable mounting post for a secondary mechanical ejector, keeping the 100 mm stroke perfectly aligned.
Label Applicator Platen
Presses adhesive labels onto cartons. The fixed rubber bumper absorbs the end-of-stroke impact, while the LB foot mount secures the body firmly to the framing.
Replacing the Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB with MBLD20X100-LB
To replace the MALD20X100-LB, specify the MBLD20X100-LB. Confirm the 20 mm bore, 100 mm stroke, G1/8 port, PT thread, and LB foot mount. Because this SKU lacks the -S magnet, it cannot support a sensor; the MBLD upgrade would require CMSG, DMSG, or EMSG switches if sensing is added later. Size using the equal-both-ways force of 132 N at 0.5 MPa.
If you need to step down, the smallest available bore is this 20 mm size. If you need to step up, the next larger bore is 25 mm, which provides 206 N at 0.5 MPa. At a 100 mm stroke on a mini bore, ensure your load is guided to prevent rod side-loading and premature seal wear.
Upgrade checklist
- ✓ Order the MBLD20X100-LB (same bore/stroke/force)
- ✓ Force equal both ways (132 N at 0.5 MPa)
- ✓ Twin rods for anti-rotation / rear flag
- ✓ No back cover / SDB — plan a body or FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Protect both rod ends from side load on long strokes.
- check No back-cover / SDB on double-rod — use body / FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLD20X100-LB instead of this discontinued model.
Airtac MALD Aluminum Alloy Mini Cylinder MALD20X100-LB FAQ
Yes, the MALD20X100-LB is discontinued. The direct replacement is the MBLD20X100-LB, which matches the 20 mm bore, 100 mm stroke, G1/8 port, and LB foot mount. The MBLD upgrades the construction with a riveted rolling-packed body instead of threaded covers.
Because a rod exits both ends, the piston sees the same annulus area on both sides, making push and pull force identical. The ratings are 132 N at 0.5 MPa, 185 N at 0.7 MPa, and a maximum of 27 kgf at 1.0 MPa. Note that this specific SKU lacks a magnet, so it cannot accept CS1-M or DS1-M position sensors.
