This model is discontinued
AirTAC has phased out the MALD series. You can still order this code here: we ship the direct replacement MBLD20X150S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLD replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S
The AirTAC Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S is a double-acting, double-rod aluminum mini cylinder: a rod exits both ends of the Ø20mm bore, so push and pull force are equal. This model is discontinued — the direct replacement is the MBLD20X150-S, matching bore, stroke, force and mounting.
- BoreØ20 mm
- Stroke150 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod
- Rod threadM8×1.25
- StatusDiscontinued → MBLD20X150-S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S
The AirTAC MALD20X150-S is a discontinued double-acting, double-rod mini cylinder. A rod exits both ends, so the annulus area is identical on each side, yielding equal push and pull force of 132 N at 0.5 MPa. The direct replacement is the MBLD20X150-S, matching the 20 mm bore, 150 mm stroke, G1/8 port, and mounting.
This -S SKU includes a magnet for position sensing. The original MALD uses CS1-M or DS1-M reed switches, while the MBLD upgrade uses CMSG, DMSG, or EMSG solid-state sensors. The legacy MALD has threaded covers, whereas the MBLD features a riveted rolling-packed body. Both lack a back cover or SDB auto-switch bracket, so you mount directly via the body or an FA/LB bracket.
Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S Technical Specifications
| Model | Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S |
|---|---|
| Series | MALD double-rod mini cylinder (discontinued) |
| Replacement | MBLD20X150-S |
| Bore size | Ø20 mm |
| Stroke | 150 mm |
| Acting type | Double acting, double rod |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
Double-rod types have no back-cover code and no SDB pivot; mount on the body, LB foot or FA flange. The MBLD20X150-S carries the same ratings.
Output Force — Equal Both Ways (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | 185 N |
| Max (@1.0 MPa) | 27 kgf | |
A rod exits both ends, so the effective area — and force — is equal in both directions. The MBLD20X150-S matches these values.
Model Code: Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S
| MALD | Double-rod aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×150 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLD uses CMSG/DMSG/EMSG). |
Replacement: MALD → MBLD. No back-cover (CA/U/CM) and no SDB on double-rod. Mounting: LB / FA.
Where the Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S Is Used
PCB Depaneling Saw
Drives a synchronized cutting blade on a printed circuit board router, using the twin rods to prevent blade yaw while applying 132 N of equal push and pull force.
Label Applicator Arm
Pivots a tamp pad on a packaging line; the rear rod carries a cam to trigger a mechanical flag, verifying stroke position without relying solely on the CS1-M sensor.
Gripper Slide Sync
Actuates a synchronized dual-jaw gripper for small electronic component pickup, ensuring both jaws close simultaneously with equal 185 N force at 0.7 MPa.
Replacing the Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S with MBLD20X150-S
To replace the MALD20X150-S, order the MBLD20X150-S. Confirm your 20 mm bore, 150 mm stroke, G1/8 port, M8x1.25 rod-end thread, and FA/LB mounting. The magnet code (-S) carries over, but you must upgrade from CS1-M/DS1-M to CMSG/DMSG/EMSG sensors. Size your loads on the equal both-ways force: 132 N at 0.5 MPa and 185 N at 0.7 MPa.
If you need to step down, the adjacent bore is not smaller for this double-rod family, so 20 mm is the minimum. Stepping up to the 32 mm bore yields 346 N at 0.5 MPa. At a 150 mm stroke, twin rods resist rotation well, but always verify the rod-to-side-load ratio to prevent bearing wear on long slides.
Upgrade checklist
- ✓ Order the MBLD20X150-S (same bore/stroke/force)
- ✓ Force equal both ways (132 N at 0.5 MPa)
- ✓ Twin rods for anti-rotation / rear flag
- ✓ No back cover / SDB — plan a body or FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Protect both rod ends from side load on long strokes.
- check No back-cover / SDB on double-rod — use body / FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLD20X150-S instead of this discontinued model.
Airtac MALD Aluminum Alloy Mini Cylinder MALD20X150-S FAQ
Yes, the MALD20X150-S is discontinued. The direct replacement is the MBLD20X150-S, matching the 20 mm bore, 150 mm stroke, G1/8 port, and mounting. The MBLD uses a riveted rolling-packed body instead of threaded covers, and its magnet works with CMSG/DMSG/EMSG sensors instead of the older CS1-M/DS1-M switches.
Because it is a double-rod cylinder, push and pull forces are equal: 132 N at 0.5 MPa, 185 N at 0.7 MPa, and a maximum of 27 kgf at 1.0 MPa. It uses a fixed rubber bumper at end-of-stroke to soften impact; it is not an adjustable cushion and will not hold the load on air loss.
