This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBLD25X25 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBLD25X25 in place of this model. The MBLD replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25
The AirTAC Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25 is a double-acting, double-rod aluminum mini cylinder: a rod exits both ends of the Ø25mm bore, so push and pull force are equal. This model is discontinued — the drop-in replacement is the MBLD25X25, matching bore, stroke, force and mounting.
- BoreØ25 mm
- Stroke25 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod
- Rod threadM10×1.25
- StatusDiscontinued → MBLD25X25
About the Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25
The AirTAC MALD25X25 is a discontinued double-acting, double-rod pneumatic cylinder. A rod exits both ends, meaning push and pull forces are perfectly equal at 206 N each way at 0.5 MPa. The exact drop-in replacement is the MBLD25X25, matching the 25 mm bore, 25 mm stroke, G1/8 port, and mounting footprint.
This cylinder has no magnet (-S) and cannot accept a position sensor. Unlike the threaded covers on this MALD, the MBLD replacement uses a riveted rolling-packed body for higher structural integrity. With no back cover or SDB auto-switch slot, you mount directly on the body or via FA/LB accessories.
Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25 Technical Specifications
| Model | Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25 |
|---|---|
| Series | MALD double-rod mini cylinder (discontinued) |
| Replacement | MBLD25X25 |
| Bore size | Ø25 mm |
| Stroke | 25 mm |
| Acting type | Double acting, double rod |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
Double-rod types have no back-cover code and no SDB pivot; mount on the body, LB foot or FA flange. The MBLD25X25 carries the same ratings.
Output Force — Equal Both Ways (Ø25mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 206 N | 206 N |
| 0.7 MPa | 289 N | 289 N |
| Max (@1.0 MPa) | 42 kgf | |
A rod exits both ends, so the effective area — and force — is equal in both directions. The MBLD25X25 matches these values.
Model Code: Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25
| MALD | Double-rod aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 25 | Bore size in mm (20/25/32/40). |
| ×25 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLD uses CMSG/DMSG/EMSG). |
Replacement: MALD → MBLD. No back-cover (CA/U/CM) and no SDB on double-rod. Mounting: LB / FA.
Where the Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25 Is Used
PCB Depaneling Router
Resists side-loading on the 25 mm stroke while delivering equal 206 N push and pull to cleanly sever populated circuit boards without rotational drift.
Connector Insertion Press
Uses the twin-rod anti-rotation property to press pin headers flat, applying 289 N at 0.7 MPa without cocking the delicate plastic housing.
Pneumatic Gripper Sync
Drives a synchronized external jaw mechanism where the rear rod acts as a mechanical flag, ensuring the 42 kgf max tooling force stays perfectly balanced.
Replacing the Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25 with MBLD25X25
To replace the MALD25X25, order the MBLD25X25. Confirm the 25 mm stroke, G1/8 port, PT thread, and FA or LB mounting (there is no back cover or SDB code). Because this SKU lacks the -S magnet, it cannot hold a sensor; if you need position detection, specify MBLD25X25S and upgrade from the old CS1-M / DS1-M switches to the CMSG / DMSG / EMSG family.
Size on the equal 206 N force at 0.5 MPa. If you need less force, step down to the 20 mm bore providing 132 N. If your application requires more thrust, step up to the 32 mm bore delivering 346 N at 0.5 MPa.
Upgrade checklist
- ✓ Order the MBLD25X25 (same bore/stroke/force)
- ✓ Force equal both ways (206 N at 0.5 MPa)
- ✓ Twin rods for anti-rotation / rear flag
- ✓ No back cover / SDB — plan a body or FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Protect both rod ends from side load on long strokes.
- check No back-cover / SDB on double-rod — use body / FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLD25X25 instead of this discontinued model.
Airtac MALD Aluminum Alloy Mini Cylinder MALD25X25 FAQ
Yes, the MALD25X25 is discontinued. The direct drop-in replacement is the MBLD25X25, which matches the 25 mm bore, 25 mm stroke, G1/8 port, and equal 206 N force. You will need to upgrade your sensor family if switching from an -S version.
Because it is a double-rod cylinder, the push and pull forces are equal: 206 N at 0.5 MPa and 289 N at 0.7 MPa, with a maximum force of 42 kgf at 1.0 MPa. It uses a fixed rubber bumper at both stroke ends and does not feature an adjustable cushion.
