Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S
SUS304 stainless variant (-S)The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S
The PEB1001-S is an AirTAC PEB male branch tee from the resin one-touch range, joining Dia 10 mm soft nylon or polyurethane tube to a 1/8 in PT male thread. Push the tube home and the internal chuck grips it; press the POM release ring against the guide and the tube is freed. The male thread arrives with sealant already applied, so it seals straight into a PT port without extra tape or compound.
As a resin-line fitting it is rated 0-1.0 MPa working pressure, -750 mmHg vacuum, 1.5 MPa proof pressure and -20 to +70 C. The -S suffix changes none of those figures: on a PEB the body stays PBT and only the male stud becomes SUS304. What you gain is a corrosion-resistant thread where the fitting meets the port, not a solid stainless body.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S Is Used
Vacuum ejector branch on a carton sealer
Tee a Dia 10 leg off the main air run to feed the vacuum ejector that holds the flap square while the hot-melt bead cures, all from a single 1/8 PT port on the manifold.
Rinse-zone air on an electroplating line
The SUS304 male stud resists the alkaline mist that attacks a plain brass thread at the port, while the light PBT tee body carries the Dia 10 branch to the agitation blow line.
Chip-blowoff drop on a job-shop mill
Branch a Dia 10 leg to the air nozzle that clears chips from the drilling fixture between cycles, teed straight off the machine's 1/8 PT outlet without cutting the main feed.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S the Right Part?
PEB on a 1/8 in thread exists only in Dia 4, 6, 8 and 10, so PEB1001-S sits at the top of that ladder. The size down is PEB801 on Dia 8 tube, and there is no Dia 12 option at 1/8 in - for the larger bores step up the thread to PEB1002 or PEB1202 on 1/4 in. Match the 1/8 PT stud to the port you are branching into, and check the collet size: it accepts exactly Dia 10 tube, and a smaller tube will leak or blow out under pressure.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1001-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. This SKU joins Dia 10 tube to a 1/8 in PT male thread, and the SUS304 stud replaces the brass one without changing a single rating.
No. On PEB tees the -S suffix puts SUS304 on the male stud only; the tee body stays PBT, with a POM release ring, aluminium-alloy guide, stainless spring gasket and NBR seal. Solid SUS304 bodies in this range are limited to the PC and POC straight connectors, so do not expect the tee shell itself to be stainless.
