Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D
The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D
The PEB1003D is an AirTAC PEB male branch tee, the fitting you use when one 3/8in PT port has to feed two Dia 10 mm tubes at 90 degrees to each other. The male thread lands in the port, and the two push-in ports take soft nylon or polyurethane tube straight into the chuck. Push the tube home and the stainless spring gasket grips it; press the release ring and it slides free again.
This is the resin one-touch spec profile, not the metal line: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, temperature -20 to +70 C. The D suffix on this series makes the whole body black rather than the standard grey, and the male thread arrives from AirTAC already coated with sealant, so no extra tape or paste is needed on assembly.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D Is Used
Packaging machine drop from a manifold
Branching a Dia 10 supply off a 3/8in manifold port to feed a case-erector clamp cylinder, with the black body blending into dark machine framing.
Rotary indexer air feed
A perpendicular branch off a 3/8in port to run Dia 10 tube to the index table's brake port while the main line continues to the drive cylinder.
Plating line rinse-actuation circuit
Feeding two Dia 10 valve lines from one 3/8in threaded outlet on a rinse-tilt actuator station, using the sealant-coated thread for a fast, leak-free make-up.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D the Right Part?
On the PEB ladder at 3/8in thread, this Dia 10 sits between the PEB803 (Dia 8 tube) below and the PEB1203 (Dia 12 tube) above. Stepping down to Dia 8 gives you a slimmer grip and suits lighter actuators; stepping up to Dia 12 lowers restriction on longer runs to big-bore cylinders. If your port is 1/4in instead of 3/8in, the matching part is the PEB1002, which supports the same Dia 10 tube. Remember the tube OD must match the fitting exactly - a Dia 10 port will not seal on 3/8in or 12 mm tube.
A branch tee (PEB) puts both tube ports on one side of the thread axis, which matters when the second line must turn perpendicular to the panel or manifold face. If you need the second line to continue in line with the first, that is the PED run tee instead. For a pass-through a panel wall, use the PMF bulkhead connector rather than forcing a tee to do a panel job.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1003D FAQ
It is an AirTAC PEB male branch tee for Dia 10 mm tube with a 3/8in PT male thread. Working pressure is 0-1.0 MPa (0-10 kgf/cm2), it holds vacuum to -750 mmHg (10 Torr), proof pressure is 1.5 MPa, and the temperature range is -20 to +70 C. Applicable tubing is soft nylon or polyurethane, the body is black PBT with a brass stud, and the thread arrives pre-coated with sealant.
On the PEB branch tee, both push-in ports sit on the same side of the male thread, so both tube lines leave perpendicular to the mounting face. On the PED run tee, one port continues in line with the thread axis. Pick the PEB1003D when the second Dia 10 line must turn at 90 degrees away from the port, such as branching to a clamp or brake circuit; pick a PED when the main line should carry on straight through.
