Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D
The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D
The PEB1004D is an AirTAC PEB male branch tee in the resin one-touch range, joining a Dia 10 mm tube to a 1/2in PT male thread and carrying the black D-suffix finish, which on this family means the body itself is black rather than just the button. A branch tee sends air at 90 degrees off a straight run, so one port feeds downstream while the tee leg serves a separate actuator or gauge.
Installation is push-in: slide the soft nylon or PU tube into the chuck until it seats, and the stainless spring gasket plus POM chuck lock it against the 0-1.0 MPa working pressure; press the POM release ring to free it. Rated to 1.5 MPa proof pressure, -750 mmHg vacuum and -20 to +70 C. Every 1/2in thread arrives with sealant pre-applied, so no extra tape is needed on the port.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D Is Used
Valve manifold branch take-off
Tee a Dia 10 supply run off a 1/2in PT manifold port to feed a separate valve station without cutting in a union tee and elbow.
Packaging machine drop leg
Branch a Dia 10 line at the machine frame to serve a vacuum generator or air knife while the run continues downstream to the next station.
Conveyor air-blow spurs
Feed two nozzle lines from one 1/2in threaded supply point, using the 90 degree leg to aim the branch across the belt line.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D the Right Part?
On the PEB 1/2in ladder the neighbouring sizes are PEB804D (Dia 8 tube) below and PEB1204D (Dia 12) above. Stepping to Dia 8 buys compactness on shorter runs; Dia 12 suits larger bore circuits where you want the branch leg on the same generous line. The thread stays 1/2in across all three, so the port thread is not the decision - the tube is.
The branch shape is the right answer when a run needs to split without adding a union tee plus a separate male elbow. Confirm the tube OD matches exactly: a Dia 10 fitting will not grip 3/8in (10 mm nominal Imperial) or 12 mm tube. If stainless matters, note that a PEB-S keeps the PBT body and only the stud becomes SUS304.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1004D FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), proof pressure 1.5 MPa, vacuum to -750 mmHg (10 Torr), operating temperature -20 to +70 C. It joins a Dia 10 mm tube to a 1/2in PT male thread, with the black D-finish body. applicable tubing is soft nylon or polyurethane.
No. On PC and POC straight connectors the D suffix changes only the release button, but on the PEB family it changes the whole body to black. Either way the mechanical spec is identical: same 1.0 MPa rating, same temperatures, same PT thread standard.
