Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S
SUS304 stainless variant (-S)The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S
The PEB1202-S is an AirTAC PEB male branch tee from the resin one-touch family: a Dia 12 mm tube pushes into the branch leg and a 1/4 in PT male stud forms the feed. Push the tube home and the internal chuck grips it; press the release ring and the collet frees it again. Under the -S suffix, the stud on the threaded leg is SUS304 stainless steel while the tee body remains the standard PBT, so the shape and every dimension match the grey PEB1202 exactly.
It runs the resin spec profile: 0-1.0 MPa working pressure, -750 mmHg (10 Torr) vacuum, 1.5 MPa proof pressure and -20 to +70 C on soft nylon or polyurethane tubing. Inside you find a POM release button and chuck, an aluminium-alloy guide, a stainless spring gasket and an NBR O-ring. The 1/4 in stud arrives with sealant pre-applied on the thread, so it seats into a PT port without additional tape.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S Is Used
Valve island pilot branch
Tapping a Dia 12 trunk line on a carton-wrapper machine to feed the pilot ports of a 5/2 valve bank, with the 1/4 in stud landing directly on the manifold port.
Weld-cell clamp takeoff
Branching off the Dia 12 supply drop in an automotive weld cell to feed pallet-clamp actuators, the 90 degree branch turning the line away from the guard wall.
CNC fixture feed
Taking a compressed-air branch off the machine-bed line on a machining centre to power a vise or workrest clamp, using the full 12 mm bore for fast fill times.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S the Right Part?
Dia 12 is the top of the ladder for a 1/4 in thread on the PEB prefix - there is no step up from PEB1202. The neighbour below is PEB1002 (Dia 10, same thread), which drops the bore and the pull-out load but still serves most cylinder and valve lines; step down only when the circuit is genuinely 10 mm. If the port itself is 3/8 in or 1/2 in instead, AirTAC lists PEB1203 and PEB1204 for the same Dia 12 tube. Match the tube OD exactly: a Dia 12 chuck will not seal on 10 mm or on imperial hose. Note the geometry too - a PEB branch tee passes the run straight through with the branch at 90 degrees, so if the piping pattern needs a true run tee, order PED rather than forcing the branch layout.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1202-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure to -750 mmHg (10 Torr), proof pressure 1.5 MPa and a temperature range of -20 to +70 C. This SKU joins Dia 12 mm soft nylon or polyurethane tubing to a 1/4 in PT male thread.
On the -S version of this branch tee the SUS304 part is the stud on the threaded leg. The tee body stays PBT, and the POM release button, aluminium guide, stainless spring gasket and NBR O-ring are unchanged from the standard PEB1202. AirTAC publishes no corrosion class, passivation or food certification for this line, and the pressure, temperature and dimension tables are identical to the grey version - so never re-rate it.
