Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S
SUS304 stainless variant (-S)The AirTAC Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S is a genuine male branch tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale branch tee
- SeriesPEB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S
The PEB1204D-S is AirTAC's PEB male branch tee in its largest arrangement: Dia 12 mm tubing on a 1/2in PT male thread, finished in the D black body colour, with the male stud machined in SUS304 stainless steel. Unlike a run tee, the branch port leaves the through-line at 90 degrees while both tube legs stay in line, so a tee can be spliced straight into a main drop and the branch still points exactly where the actuator needs it. Push the 12 mm tube home and the internal chuck grips it; press the release ring and it frees.
This is the resin/brass spec profile, not the metal 0.9 MPa line: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg (10 Torr), proof pressure 1.5 MPa, temperature -20 to +70 C, for soft nylon or polyurethane tubing. The stud arrives with sealant already on the PT thread, and the release button, chuck and NBR O-ring carry over from the standard PEB - the -S change is the stud material, not the shape or the ratings.
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S Technical Specifications
| Model | Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S |
|---|---|
| Type | Male branch tee |
| Series | PEB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S
| PEB | Male branch tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S Is Used
Palletiser drop-line branch
Splice the tee into a 12 mm vertical drop on a palletising cell and branch off at 90 degrees to feed the gripper cylinder, without re-routing the main line.
Belt cleaner actuator take-off
On a conveyor head pulley, a 1/2in PT port on the air header takes the stud while the 12 mm legs carry the main supply past to the next station.
Wash-down rinse header branch
The SUS304 stud suits a food-plant rinse cabinet where the 1/2in branch feeds a spray-bar valve from a copper-free-sensitive line.
Is the Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S the Right Part?
On the 1/2in thread you can step down to PEB1004D-S (Dia 10 mm), the only smaller tube size AirTAC lists on 1/2in for PEB; going below that means dropping to a 3/8in stud. On the tube side, PEB1203D-S keeps the full Dia 12 bore but reduces the stud to 3/8in PT, useful when the port is smaller than the line. There is no step up: Dia 12 is the largest tube and 1/2in the largest thread in the PEB ladder, so this SKU is the top of the range. Whichever way you go, tube OD must match exactly - a Dia 12 chuck will not seal on 10 mm or on 1/2in imperial tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEB T-Shaped Straight Thread Tee Connector PEB1204D-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. The tube diameter is 12 mm on both through legs and branch, the male thread is 1/2in PT, and the D suffix is AirTAC's black body colour.
No. On PEB parts the -S makes the male stud SUS304 stainless steel; the body stays PBT, and the pressure, temperature and size tables are identical to the standard PEB1204D. Buyers who need a fully stainless body are directed to the PC or POC straight connectors, where the body itself is 304.
