Airtac PED T-Shaped Side Thread Tee Fitting PED1001
The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED1001 is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED1001
The PED1001 is an AirTAC PED male run tee from the resin one-touch range. It carries two Dia 10 mm sockets for soft nylon or polyurethane tube and puts a 1/8in PT male thread on the run itself. Push each tube home and the internal chuck grips it around the OD; press the release ring and the tube frees again. Resin-line ratings: 0-1.0 MPa working pressure, 1.5 MPa proof pressure, vacuum to -750 mmHg (10 Torr), usable from -20 to +70 C.
Run tee is the operating word: on a PED the male thread lies on the run axis, so flow can pass straight through the body while a third leg tees off sideways. That is the split from the PEB branch tee, where the thread sits on the perpendicular branch instead. The body is PBT over a brass stud, and the thread leaves the factory with sealant already applied - extra tape at assembly is unnecessary.
Airtac PED T-Shaped Side Thread Tee Fitting PED1001 Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED1001 |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED1001
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED1001 Is Used
Valve manifold drop on a palletiser
Two 10mm tube runs pass straight through the tee while the 1/8in thread lands on the valve manifold outlet, feeding the layer-gripper cylinder without adding an elbow to the run.
Vacuum sheet-feed station on a printing press
The -750 mmHg (10 Torr) negative rating lets this same tee sit in the suction side, picking up vacuum-cup lines on a feed table while the threaded leg ties into the venturi supply.
Guard-interlock chain on a textile ring winder
Interlock actuators along a winder daisy-chain down the machine length; the in-line thread lets each tee pick up a solenoid feed without breaking the 10mm main run.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED1001 the Right Part?
Stepping down lands on PED801 (Dia 8 on 1/8in), which trims the bore and the air volume the tee passes - adequate for a signal or clamping line, thin for a fast-stroking cylinder. PED1001 is the ceiling for a 1/8in thread on the PED ladder: there is no Dia 12 at 1/8in, so a Dia 12 run means moving to PED1202 on a 1/4in thread. Match the thread to the port hand-tight first; if it takes more than a few turns to seat, the port is probably 1/4in and you need the 02 suffix. Tube OD must match exactly - a Dia 10 socket holds only Dia 10 tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED1001 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2); negative pressure down to -750 mmHg (10 Torr); proof pressure 1.5 MPa; temperature -20 to +70 C. Size: two Dia 10 mm tube sockets on the run with a 1/8in PT male thread, resin one-touch body (PBT with brass stud, POM chuck, NBR seal).
Not in the same body - a one-touch socket grips exactly one tube OD, so this fitting accepts Dia 10 tube only. Use PED801 for a Dia 8 run at 1/8in, or keep the 10mm run and add a PG10-8 straight reducer downstream where the 8mm branch starts.
