Airtac PED T-Shaped Side Thread Tee Fitting PED1002
The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED1002 is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED1002
The AirTAC PED1002 is a male run tee from the resin one-touch fitting family. It offers two push-in ports for Dia 10 mm soft nylon or polyurethane tube plus a 1/4 in PT male stud that sits in the run, in line with one tube leg rather than hanging on the branch - the shape to pick when the threaded source should carry the straight-through flow.
To connect, push the tube home past the POM chuck and it grips; press the release ring and the tube frees. This SKU is the resin spec profile, not the metal BP line: working pressure 0-1.0 MPa, vacuum to -750 mmHg, proof pressure 1.5 MPa, temperature -20 to +70 C. The body is PBT with a brass stud, the thread arrives pre-coated with sealant, and the standard colour is grey.
Airtac PED T-Shaped Side Thread Tee Fitting PED1002 Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED1002 |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED1002
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED1002 Is Used
Assembly cell air drops
On a benchtop assembly cell, the 1/4 in PT stud drops straight into the regulator outlet while the two Dia 10 mm legs feed a clamping cylinder on one side and a swing clamp on the other.
Cartoning machine grippers
Cartoning machines often run paired grippers from a single supply leg; the PED1002 splits that 10 mm line at the manifold so each gripper gets its own push-in connection without extra threaded joints.
Solenoid bank supply tee
Screw the stud into the 1/4 in inlet of a valve manifold on a bottling line and run the two tube ports onward to pilot circuits, cutting the number of threaded ports the panel needs.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED1002 the Right Part?
Both directions of the size ladder are covered on this thread: step down to PED802 for Dia 8 mm lines feeding smaller actuators, or up to PED1202 for Dia 12 mm to larger cylinders. The bore change is what alters capacity qualitatively, since AirTAC publishes flow for this family only as a characteristic curve. In Dia 10 the same shape also exists as PED1001 (1/8 in), PED1003 (3/8 in) and PED1004 (1/2 in), so match the stud to the port you actually have. Tubing must be soft nylon or polyurethane and the OD must be exactly Dia 10 - a slightly undersized or oversized tube will not seal or release correctly.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED1002 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, temperature -20 to +70 C. Size: two push-in ports for Dia 10 mm tube and a 1/4 in PT male stud. Body is PBT with a brass stud, sealant is pre-applied to the thread, and the applicable tubing is soft nylon or polyurethane only.
Both are male tees for Dia 10 mm tube, but on PED the male stud sits in the run, in line with one tube port, so the screw-in connection carries the straight-through flow. On PEB the stud is the 90 degree branch and the straight run is tube-to-tube. Pick PED when the threaded source should feed straight through; pick PEB when the thread should hang off the side of the line.
