Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S
SUS304 stainless variant (-S)The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S
The PED1202-S is an AirTAC PED series male run tee, the resin one-touch shape whose male thread sits in line with the straight-through run and whose single branch leaves at 90 degrees. This SKU joins two Dia 12 mm soft nylon or polyurethane tube lines to a 1/4 inch PT male thread. Push each tube home and the chuck grips it around the spring gasket; press the POM release ring and the tube frees again. The threaded port arrives with sealant already applied, so it is ready to wind straight into a PT tapped hole.
This is the standard resin pressure profile, not the metal BP line: 0 to 1.0 MPa working pressure, 1.5 MPa proof pressure, vacuum to -750 mmHg, and -20 to +70 C. The -S suffix fits a SUS304 stud to the male thread while the body remains PBT and the release ring, chuck and guide stay as the standard part, so the exposed thread keeps its integrity in damp or mildly corrosive air without any rating or dimension changing.
Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S Is Used
Valve manifold takeoff on a palletizer
Screw the 1/4 inch PT stud into the spare station on a 5/2 valve manifold, keep the Dia 12 supply run flowing straight through, and branch off at 90 degrees to feed a large-bore cylinder without adding a second coupling.
Washdown food-line frame plumbing
On a conveyor or filler frame hosed down between shifts, the SUS304 stud on the threaded leg stands up to the damp environment better than a plain brass stud, while the PBT body ports stay standard.
Twin-cylinder feed on a gantry clamp
TwoDia 12 lines, one supply point: the run tee lets the main Dia 12 air line continue past the clamp station while the branch drops down to the second cylinder port below it.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S the Right Part?
Dia 12 is the largest tube size in this one-touch catalogue, so there is nothing to step up to; if your flow demand exceeds a 12 mm bore the answer is a different circuit, not a bigger PED. Step down to PED1002 for a Dia 10 tube on the same 1/4 inch thread when the branch feeds a lighter actuator and a smaller fitting footprint helps. If the tapped port is 3/8 inch instead, PED1203 keeps the same Dia 12 tube on the larger thread.
Match the thread to the port: PT is a taper thread and relies on the factory-applied sealant, so do not mate it to a dry parallel port. If the line has to pass through a panel or tank wall, the PMF bulkhead connector is the right shape instead; if two tube lines meet at a corner with no straight-through run, compare the PEB branch tee. Whichever shape you land on, the tube OD must match exactly - a Dia 12 chuck will not seal on any other size.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED1202-S FAQ
Working pressure 0 to 1.0 MPa (0-10 kgf/cm2), negative pressure down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and an operating temperature range of -20 to +70 C. The fitting accepts Dia 12 mm soft nylon or polyurethane tube on both push-in ports and provides a 1/4 inch PT male thread on the run.
On the PED family the -S option fits a SUS304 stud to the male thread; the body stays PBT and the release ring, chuck, guide and O-ring are unchanged. Working pressure, temperature range and every dimension match the standard PED1202, so it drops straight into the same tapped hole. The grade is 304, no other finish or certification figures are published, and no flow coefficient exists for it - capacity tracks the 12 mm bore.
