Airtac PED T-Shaped Side Thread Tee Fitting PED401D
The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED401D is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED401D
The PED401D is an AirTAC PED male run tee in the black colour option, joining Dia 6 mm soft nylon or polyurethane tube to a 1/8 inch PT male thread. Its defining geometry is the run-through path: flow continues in a straight line past the threaded branch, while a 90 degree outlet drops off the side. That makes it the fitting of choice where a branch feed has to come off a line without introducing two extra elbows and the pressure penalty that comes with them.
As a resin one-touch part it is rated 0 to 1.0 MPa working pressure, 1.5 MPa proof pressure, and -750 mmHg (10 Torr) vacuum, usable from -20 to +70 C. Push the 6 mm tube home and the internal chuck grips it; press the POM release ring to free it. Because this is a PED rather than a PC or POC, the D suffix changes the body as well as the release button to black. The 1/8 inch thread arrives with sealant already applied, so it seals on tightening without extra tape.
Airtac PED T-Shaped Side Thread Tee Fitting PED401D Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED401D |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED401D
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED401D Is Used
Vacuum pickup on a PCB handling cell
The -750 mmHg rating lets a Dia 6 vacuum line run through the tee to an ejector at a pick point, while the through-path keeps the same supply feeding a second station downstream.
Reject pusher takeoff on a bottling line
Thread the 1/8 inch stud into the pusher cylinder port and let the Dia 6 main run continue along the conveyor frame, splitting supply to the reject actuator with one fitting instead of an elbow plus a tee.
Black-out pipework on a pick-and-place robot
Where a machine builder specifies black fittings on the robot dress pack, the D suffix gives a black body and release ring on the same 0-1.0 MPa resin platform, with the 1/8 inch stud landing straight on the valve manifold.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED401D the Right Part?
Dia 6 sits in the middle of the PED run on a 1/8 inch port. Stepping down to Dia 4 trims the bore for light pilot and signalling duties; stepping up to Dia 8 increases the available cross-section for cylinders with meaningful draw. On the thread side, this exact tube size is also offered with M5 and 1/4 inch, so you can match either a small sensor port or a larger manifold tapping without changing tube. Every combination must come from the PED row of the interface table; 1/8 inch with Dia 6 is confirmed in it.
Match the shape before you match the size: if the branch can carry the whole flow and nothing passes through, a PEB male branch tee is the simpler part, and a PE union tee handles all-tube junctions with no thread at all. One rule is absolute - the tube OD must equal the fitting size exactly, so a Dia 6 gripping chuck will not seal on 1/4 inch (6.35 mm) tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED401D FAQ
It is an AirTAC PED male run tee for Dia 6 mm tube with a 1/8 inch PT male thread, in black (D suffix). Working pressure is 0 to 1.0 MPa (0 to 10 kgf/cm2), vacuum capability is -750 mmHg (10 Torr), proof pressure is 1.5 MPa, and the temperature range is -20 to +70 C. It takes soft nylon or polyurethane tubing and the thread is supplied with sealant pre-applied.
On the PED family the D changes the body as well as the release button to black; the pressure, vacuum and temperature ratings and the dimensions are identical to the grey PED401. A separate point worth knowing: only the threaded ports carry sealant, so any tube-side joint depends on the chuck and O-ring alone and never needs tape on the tube itself.
