Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S
SUS304 stainless variant (-S)The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S
The PED401D-S is an AirTAC male run tee from the resin one-touch fitting family, joining two Dia 4 mm tube lines in a straight through-run while a 1/8 inch PT male thread branches off at 90 degrees. Push the soft nylon or polyurethane tube into each port and the internal chuck grips it positively; press the release ring to free it. The D suffix gives the black body colourway.
The -S variant keeps the standard resin spec - 0-1.0 MPa working pressure, -750 mmHg vacuum and -20 to +70 C - and does not change the dimensions. What it changes is the fixing stud: on PED-family parts the body stays PBT while the threaded stud is SUS304, so the leg that screws into your port resists corrosion and stands up to humid or washdown-adjacent panels. The thread ships with sealant applied, so a wrench-and-go install is normal; the M5 sizes in this catalogue are the ones that use a sealing gasket instead.
Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S Is Used
Analytical instrument sample-air tee
Split a 4 mm sample-air line inside a benchtop gas analyzer: the run continues to the cell while the 1/8 inch PT branch feeds a low-pressure switch, with the SUS304 stud coping with humid exhaust-side air.
SMD pick-head vacuum branch
On a desktop pick-and-place head, run the Dia 4 vacuum line straight through between nozzles and take the 1/8 inch threaded branch to a compact vacuum filter or sensor.
Pilot-signal tap on an air-jet loom
Tap a Dia 4 pilot line on a textile loom's jet-control manifold: the main signal passes through the tee and the threaded leg carries the small pressure gauge used for jet timing setup.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S the Right Part?
Dia 4 is the smallest tube size AirTAC makes in this series, so there is no smaller sibling - if you step down from here you change technology, not size. On the same 1/8 inch thread the next rung up is PED601 (Dia 6), which adds bore for slightly hungrier actuators; on the same Dia 4 tube the thread options are PED4M5 with its M5x0.8 gasket-sealed port or PED402 for a 1/4 inch port. Match the thread to the receiving port first, then confirm tube OD: a Dia 4 chuck will not seal on 1/8 inch (3 mm) imperial tube, which is a different catalogue entirely.
Choose a run tee over a branch tee when the incoming line must continue straight through to a second leg - for example a probe line feeding onward to another station - with the threaded port kept for the gauge, pilot valve or vacuum generator on the branch.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED401D-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2); negative pressure -750 mmHg (10 Torr); proof pressure 1.5 MPa; temperature -20 to +70 C. It joins Dia 4 soft nylon or polyurethane tube to a 1/8 inch PT male branch thread. Construction is a black PBT body with SUS304 stud, aluminium-alloy guide, stainless spring gasket, POM release button and NBR O-ring.
No, and knowing this avoids surprises. On PED-series parts the -S means the threaded stud is SUS304 while the body remains PBT (only the PC and POC straight connectors get a full SUS304 body). Pressure, vacuum, temperature ratings and all dimensions are identical to the standard PED401D, so nothing needs re-rating on your drawing.
