Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D
The AirTAC Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D is a genuine different diameter tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeDifferent diameter tee
- SeriesPEW
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D
The PEW12-10D is an AirTAC PEW different diameter union tee: a tube-to-tube, three-way fitting that splits a Dia 12 mm main line into a Dia 10 mm branch without any threaded port in between. Both outer ports take the larger 12 mm tube, the branch takes 10 mm, so a single part does the work of a tee plus a reducer. Push each tube home until it bottoms in the chuck and the stainless spring gasket grips it; press the POM release ring to free it again.
This is the resin and brass one-touch profile, not the metal BP line: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a service range of -20 to +70 C. The body is black because the D suffix on this family changes the whole body colour, not just the release button as it does on PC and POC straight connectors. Tubing must be soft nylon or polyurethane; the chuck is not designed to seal on rigid or thick-wall hose.
Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D Technical Specifications
| Model | Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D |
|---|---|
| Type | Different diameter tee |
| Series | PEW |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D
| PEW | Different diameter tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D Is Used
Packaging machine branch line
Split a Dia 12 mm nylon main feed on a cartoning or wrapping machine into a Dia 10 mm branch that supplies a downstream pneumatic gripper or clamp cylinder, in one push-fit part.
Black tubing in visible frames
On extruded-aluminium machine frames and robotics cells dressed with black 12 mm and 10 mm polyurethane tubing, the D-suffix black body keeps the air routing visually consistent instead of showing grey fittings mid-run.
Vacuum pick-and-place split
Rated to -750 mmHg, so a Dia 12 mm vacuum line from the ejector can be teed and stepped down to Dia 10 mm drops feeding suction cups on a sheet-handling or carton-raising station.
Is the Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D the Right Part?
Step down to PEW10-8 when your main line is 10 mm and the branch actuator needs 8 mm - everything else about the part stays the same. There is no larger variant: Dia 12 is the biggest tube size in this catalogue, so PEW12-10 is already at the top of the different-diameter ladder. If both legs are the same diameter, a plain PE union tee is the lighter answer; if you want a swept Y rather than a right-angle branch, the PYW different diameter union Y is the equivalent shape.
Tube OD must match each port exactly - the 12 mm ports will not hold 10 mm tube and the 10 mm branch will not hold 12 mm, so measure the actual tube wall-marking before ordering. Capacity is set by the smaller bore: expect the 10 mm branch to pass less air than the 12 mm through-flow.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PEW T-Type Side Reducing Tee Fitting PEW12-10D FAQ
It is a different diameter one-touch union tee joining Dia 12 mm tube on the two through-ports to Dia 10 mm tube on the branch, finished black (D suffix). Working pressure is 0-1.0 MPa (0-10 kgf/cm2), negative pressure goes to -750 mmHg (10 Torr), proof pressure is 1.5 MPa, and the temperature range is -20 to +70 C. Use soft nylon or polyurethane tubing only.
No. Each port grips one tube OD only: the two in-line ports accept Dia 12 mm and the branch accepts Dia 10 mm. A 12 mm fitting will not seal on 10 mm tube or the reverse, because the chuck and gasket are sized to the exact wall diameter. If you need equal diameters throughout, order a standard PE union tee in a single size instead.
