Airtac PHW F Thread Swivel Tee Fitting PHW601D
The AirTAC Airtac PHW F Thread Swivel Tee Fitting PHW601D is a genuine double universal male elbow for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeDouble universal male elbow
- SeriesPHW
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PHW F Thread Swivel Tee Fitting PHW601D
The PHW601D is an AirTAC PHW double universal male elbow, a one-touch fitting that connects Dia 6 mm soft nylon or polyurethane tubing to a 1/8 in PT male port. Push the tube home and the stainless spring gasket plus the chuck grip it firmly; press the POM release ring and it frees again. What sets PHW apart from the single universal PH is the second swivel: the tube end articulates independently of the thread end, so the line can leave in a different plane than the port faces.
This part follows the resin and brass one-touch profile, not the metal BP line: 0-1.0 MPa working pressure, 1.5 MPa proof, -750 mmHg vacuum and -20 to +70 C. The D suffix turns the whole body black, not just the release button, which helps where grey fittings vanish against dark machine guards. The thread arrives with sealant pre-applied, so no tape is needed. One quirk of the series: the PHW ladder starts at 1/8 in and offers no M5, unlike its siblings PH and PHF.
Airtac PHW F Thread Swivel Tee Fitting PHW601D Technical Specifications
| Model | Airtac PHW F Thread Swivel Tee Fitting PHW601D |
|---|---|
| Type | Double universal male elbow |
| Series | PHW |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PHW F Thread Swivel Tee Fitting PHW601D
| PHW | Double universal male elbow. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PHW F Thread Swivel Tee Fitting PHW601D Is Used
Clamp cylinder on a press fixture
When the cylinder port faces sideways but the tube run must drop vertically past the tooling, the double universal elbow bends the Dia 6 PU line through two planes without kinking.
Valve manifold drop in a control panel
Screwed into a 1/8 in manifold outlet, the swivel aims the tube past neighbouring valves while the black body stands out clearly against grey wiring duct.
Pick-and-place gripper plumbing
Gripper ports sit at awkward angles and shift with the arm; a double universal elbow at each 1/8 in port lets Dia 6 nylon tube leave cleanly instead of taking a sharp side load.
Is the Airtac PHW F Thread Swivel Tee Fitting PHW601D the Right Part?
Step down to PHW401 (Dia 4 on 1/8 in) for thin pilot lines feeding small valves or sensors, or up to PHW801 (Dia 8 on 1/8 in) when the same port has to supply a hungrier actuator and you want the larger bore to cut restriction. If the port itself is bigger, the next thread rung for Dia 6 tube is PHW602 at 1/4 in PT. Match the tube exactly: this chuck grips Dia 6.00 mm and nothing else, so 1/4 in tubing at 6.35 mm will not seal, and forcing it only risks a blow-off.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PHW F Thread Swivel Tee Fitting PHW601D FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum capability -750 mmHg, proof pressure 1.5 MPa, operating temperature -20 to +70 C. The fitting takes Dia 6 mm soft nylon or polyurethane tube on a 1/8 in PT male thread, and the D suffix marks the black body and release button.
No. 1/4 in tubing measures 6.35 mm outside diameter, while the chuck in the PHW601D is made for exactly Dia 6.00 mm, so the seal will never seat properly. Use genuine Dia 6 mm metric tube, or if rewiring the run is an option, step the whole circuit up to Dia 8 tube with the PHW801.
