Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 10mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke10 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R
The AirTAC PSBR6X10R is a JIS pen-size single-acting push cylinder that supplies 10.6 N of net push at 0.5 MPa via a spring-return design. Air entering the M5x0.8 port extends the rod, while an internal spring retracts it automatically. This fail-safe mechanism ensures the rod returns home if air pressure drops. A fixed TPU bumper cushions the stroke ends.
You bolt this slim mini body straight to a fixture using the direct M3x0.5 front-cover mounting thread, saving space in compact assemblies. The SUS316L stainless barrel suits damp environments, and the R axial inlet keeps plumbing perfectly in-line. Plan for a safe working load of roughly 6 N, which accounts for seal friction at about 60 percent of the rated force.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 10 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R Is Used
Panel Pusher
Uses the M3x0.5 front-mount thread to bolt directly onto a tight jig, pushing thin panels forward with 10.6 N of net force before spring retracting.
Part Eject
Ejects small molded parts off a conveyor line; the fail-safe retract ensures the rod clears the path on air loss to prevent jams.
Clamp Release
Fits into narrow end-of-arm tooling to push a lightweight clamp open, lifting about 0.5 kg vertically with a safe 2:1 margin.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R the Right Cylinder?
When sizing this 6 mm bore model, consider the next size up to ensure adequate thrust. The PSBR8 provides 18.7 N of net push at 0.5 MPa, offering a higher force ceiling if your jig approaches the 6 N safe working load. Because 6 mm is the smallest available bore, stepping down is not an option. The internal return spring sets a minimum operating pressure of 0.3 MPa before the rod will move. Confirm your ordering essentials: this configuration includes an R axial back cover inlet and no sensor magnet.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X10R FAQ
This single-acting push cylinder provides 10.6 N of net usable push at 0.5 MPa and 16.3 N at the 0.7 MPa maximum. The internal return spring requires a minimum pressure of 0.3 MPa to overcome the spring and extend the rod.
The front cover features a direct M3x0.5 mounting thread for bolting straight to a fixture, while the M5x0.8 port handles air inlet. The SUS316L stainless barrel provides corrosion resistance in compact, damp environments.
