Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 15mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke15 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR
The AirTAC PSBR6X15SR is a single-acting push pen cylinder that extends via one M5x0.8 air port and retracts via an internal spring, ensuring a fail-safe home position if air pressure drops. It supplies 10.6 N of net push at 0.5 MPa and 16.3 N at 0.7 MPa. The return spring dictates a 0.3 MPa minimum operating pressure before motion begins.
You mount this slim SUS316L stainless body straight to a fixture using the direct M3x0.5 front-cover thread, saving space in compact jigs. A fixed TPU bumper cushions the stroke ends, while the built-in magnet (-S) supports reed or electronic switches for position sensing.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 15 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR Is Used
Panel Pusher
Uses the 10.6 N push stroke to nudge lightweight electronic panels into a test socket, with the spring safely retracting the 3 mm rod when air is removed.
Part Ejector
Ejects small machined components from a tight jig via the direct M3x0.5 front mount, saving space where a bulkier bracket cannot fit.
Clamp Release
Overcomes a light spring clamp to release a delicate workpiece, relying on the SUS316L barrel for damp or washdown environments.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR the Right Cylinder?
For this 6 mm bore, the 10.6 N net push at 0.5 MPa yields a safe working load of roughly 6 N (about 60% of rated force) to account for seal friction. In vertical lift tasks with a 2:1 safety margin, expect to lift about 0.5 kg. If your application needs less force, note that this is the smallest available bore; stepping up to the 8 mm bore raises the 0.5 MPa push to 18.7 N.
The 3 mm rod provides coaxial thrust but is slender, so add an external guide for off-axis loads over the 15 mm stroke. Confirm your plumbing uses the R axial inlet and that your fixture matches the M3x0.5 front thread.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X15SR FAQ
It delivers 10.6 N of net push at 0.5 MPa and 16.3 N at 0.7 MPa. Because it is single-acting push with a return spring, it requires a minimum operating pressure of 0.3 MPa to extend the rod.
It mounts directly via an M3x0.5 thread on the front cover, eliminating separate brackets. The built-in magnet (-S) works with AirTAC reed or electronic switches for position detection.
