Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 25mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke25 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR
The AirTAC PSBR6X25SR is a single-acting push pen cylinder that extends via one M5x0.8 air port and retracts via an internal spring. It delivers 10.6 N of net push at 0.5 MPa, providing fail-safe retraction on air loss. A built-in piston magnet enables position sensing with reed or electronic switches.
This slim mini body features a SUS316L stainless barrel and bolts directly via its front-cover M3x0.5 thread. The fixed TPU bumper decelerates the stroke end. Plan for a safe working load of about 6 N (60% of the 0.5 MPa rating) to account for seal friction.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 25 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×25 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR Is Used
Panel Pusher
Uses the 10.6 N push stroke to index thin panels forward in a compact assembly jig.
Part Ejector
Spring-return fail-safe action keeps the rod clear on air loss, preventing jams at the test station exit.
Clamp Release
Direct M3x0.5 front-mount thread secures the body tightly to release small electronic components.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR the Right Cylinder?
This 6 mm bore provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. If your task needs less force, note there is no smaller bore in this series, so verify your minimum pressure requirement. If you need more power, stepping up to the 8 mm bore yields 18.7 N at 0.5 MPa. The direct front mount and spring-return fail-safe design simplify jig integration.
Confirm the 25 mm stroke fits your cycle. The R axial inlet handles in-line plumbing, while the thin Ø3 mm rod requires an external guide for off-axis loads. Above mid-speed with tooling mass, meter-out the exhaust because the fixed TPU bumper only absorbs the final few millimeters.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X25SR FAQ
It provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. The internal return spring sets a 0.3 MPa minimum pressure before the rod moves, and the cylinder fails safely retracted on air loss.
It bolts directly via a front-cover M3x0.5 thread into your fixture. The -S suffix indicates a built-in piston magnet compatible with reed or electronic switches, and the SUS316L barrel suits damp environments.
