Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 60mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke60 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR
The AirTAC PSBR6X60SR is a JIS pen-size single-acting push cylinder with a 60 mm stroke. Air entering the M5x0.8 port extends the rod, while an internal spring retracts it. This fail-safe design ensures the rod pulls home on air loss, needing just one solenoid line. It supplies 10.6 N of net push at 0.5 MPa and 16.3 N at 0.7 MPa.
The direct M3x0.5 front-cover thread bolts straight to your fixture, saving space in tight jigs. A built-in magnet enables position sensing with reed or electronic switches. The SUS316L stainless barrel suits damp environments, and a fixed TPU bumper cushions the stroke ends. Plan for a safe working load of roughly 6 N, which lifts about 0.5 kg vertically with a 2:1 margin.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 60 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×60 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR Is Used
Panel Pusher
Extends to nudge lightweight panels into a test socket. The spring safely pulls back if air drops.
Part Ejector
Pushes small parts off a belt line. The axial R inlet keeps the footprint minimal on the line.
Clamp Release
Retracts a small holding pin on command. The M3x0.5 front mount threads directly into the jig.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR the Right Cylinder?
This 6 mm bore provides 10.6 N net push at 0.5 MPa. Stepping up to the 8 mm bore yields 18.7 N, while this is the smallest available size. The internal spring requires a minimum 0.3 MPa to move the rod. The direct M3x0.5 front mount eliminates extra brackets, and the axial R inlet keeps plumbing in-line.
At the maximum 60 mm stroke for this bore, the slender 3 mm rod requires an external guide or linear bearing to prevent side-load damage. Confirm your fixture matches the M3x0.5 thread and M5x0.8 air port. The fixed TPU bumper only decelerates the last few millimeters, so meter-out the exhaust if moving real tooling mass at higher speeds.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X60SR FAQ
It delivers 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. The return spring sets a 0.3 MPa minimum pressure before the rod moves, and the cylinder fails safely retracted on air loss.
It mounts directly via the M3x0.5 front-cover thread. The SUS316L stainless barrel resists corrosion, and the built-in magnet works with reed or electronic switches for position feedback.
