Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR
The AirTAC Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR is a single acting, pull type (spring extend) pen-size mini cylinder with direct front-cover mounting (M4×0.7 thread). A single air port drives the pull stroke on a Ø10mm bore, 15mm stroke; the return spring resets the rod when air is released.
- BoreØ10 mm
- Stroke15 mm
- Port sizeM5×0.8
- Front-mount threadM4×0.7
- Acting typePull, single acting
- ReturnSpring
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR
The AirTAC PTBR10X15SR is a JIS pen-size single-acting pull cylinder. Air entering the M5x0.8 port retracts the rod, while an internal spring pushes it back out, ensuring a fail-safe extended state upon air loss. It delivers 23.5 N of net pull at 0.5 MPa and 36.7 N at 0.7 MPa.
This 10 mm bore model features a SUS316L stainless barrel and a slim body for tight jigs. It bolts directly via the front-cover M4x0.7 thread, eliminating extra brackets. A fixed TPU bumper decelerates the stroke ends. The built-in magnet (-S) supports reed or electronic switches for position sensing.
Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR Technical Specifications
| Model | Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR |
|---|---|
| Series | PTBR JIS pen-size front-mount cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm |
| Stroke | 15 mm |
| Acting type | Single acting, pull type (spring extend) |
| Front-mount thread | M4×0.7 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (pull by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod extended; applying air retracts it, and removing air lets the spring push the rod back out. Front cover carries the mounting thread (M4×0.7); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Pull Force (Ø10mm)
| Pressure | Net pull force |
|---|---|
| 0.5 MPa | 23.5 N |
| 0.7 MPa (max) | 36.7 N |
These are usable pull forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR
| PTBR | JIS pen-size front-mount single acting, pull type (spring extend) series. |
|---|---|
| 10 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R | Back cover: R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M4×0.7). Related PBR-family variants: PBR (double acting), PSBR (single-acting push).
Where the Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR Is Used
Hold-Down Clamping
Uses spring pressure to keep a workpiece extended, then pulls back to release the part when air is applied.
Retract-to-Open Gate
Spring force holds a diverter gate closed by default; air retracts the rod to open the lane.
Wire Tensioner
Maintains steady tension on a filament or wire via the fail-safe extended rod, pulling back to slacken.
Is the Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR the Right Cylinder?
If you need less force, the Ø8 bore provides 12.4 N at 0.5 MPa; stepping up to the Ø12 bore yields 33.1 N.
Because the spring holds the rod out during air loss, it is ideal for return-to-home tasks. The direct M4x0.7 front mount simplifies fixture attachment. Confirm your port plumbing uses the M5x0.8 inlet and that the Ø4 mm rod avoids side loads by using an external guide over long strokes.
Quick checklist
- ✓ Net pull force at your working pressure
- ✓ Bolt directly through the front cover (M4×0.7)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe extend on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PTBR Single Acting Square Head Compact Cylinder PTBR10X15SR FAQ
It provides 23.5 N of net pull at 0.5 MPa and 36.7 N at 0.7 MPa. Because it is single-acting pull, a minimum pressure of 0.2 MPa is required to overcome the spring and move the rod.
It mounts directly via the front-cover M4x0.7 thread. The -S suffix denotes a built-in piston magnet compatible with reed or electronic switches, and the barrel is made of SUS316L stainless steel.
