Airtac PYB Y-Type Threaded Tee Fitting PYB1001
The AirTAC Airtac PYB Y-Type Threaded Tee Fitting PYB1001 is a genuine branch y for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeBranch Y
- SeriesPYB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PYB Y-Type Threaded Tee Fitting PYB1001
The PYB1001 is AirTAC's branch Y one-touch fitting: a Y-shaped body that puts a 1/8 in PT male threaded branch onto two Dia 10 mm push-in tube ports. Push each tube home and the internal chuck grips its OD; press the POM release ring and the tube frees off again without tools.
This is the resin line, not the metal BPC family: working pressure 0-1.0 MPa, vacuum to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a -20 to +70 C temperature window. The 1/8 in male branch arrives with sealant already applied, so it threads straight into a PT port and seals on assembly.
Airtac PYB Y-Type Threaded Tee Fitting PYB1001 Technical Specifications
| Model | Airtac PYB Y-Type Threaded Tee Fitting PYB1001 |
|---|---|
| Type | Branch Y |
| Series | PYB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PYB Y-Type Threaded Tee Fitting PYB1001
| PYB | Branch Y. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PYB Y-Type Threaded Tee Fitting PYB1001 Is Used
Indexing table valve outlet splitter
On a small rotary indexing table, the valve outlet feeds a clamp cylinder and an air-assist nozzle at different angles. The Y branch takes one 1/8 in port and splits it into two 10 mm tube runs without adding a tee block or a second valve.
Bench capping machine supply take-off
A bench-top bottle capper runs two 10 mm lines - one to the capping head, one to the bottle-grip pad - from a single regulator outlet. A threaded Y at the regulator keeps both legs at the same pressure and halves the plumbing in a cramped frame.
Lab automation pneumatic distributor
In a compact liquid-handling station, a 1/8 in PT port on the solenoid manifold feeds aspirate and purge lines. The Y branch splits that port into two 10 mm polyurethane runs with a push-in connection that survives repeated panel service.
Is the Airtac PYB Y-Type Threaded Tee Fitting PYB1001 the Right Part?
On the 1/8 in thread, the PYB ladder runs Dia 4, 6, 8, 10 - so PYB1001 sits at the top of that rung. Step down to PYB801 if your circuit is on 8 mm tube and you want lower push-in insertion force and a smaller body footprint. There is no Dia 12 version on a 1/8 thread; the next step up in bore is PYB1202 on a 1/4 in port, which also gives a stiffer branch stud.
Match the thread to a PT port or use a thread adapter - this catalogue documents PT only, with no G or NPT ordering code. And match the tube exactly: the Dia 10 chuck will not seal on 3/8 in or 1/4 in Imperial tube, so measure the OD before you order.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PYB Y-Type Threaded Tee Fitting PYB1001 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), proof pressure 1.5 MPa, vacuum capability down to -750 mmHg (10 Torr), and a working temperature of -20 to +70 C. The tube ports take Dia 10 mm soft nylon or polyurethane tubing and the branch thread is 1/8 in PT male with factory-applied sealant.
No. Both push-in ports on the PYB1001 are Dia 10 mm chucks, and tubing must match the rated OD exactly - a Dia 10 chuck will not grip 8 mm or 12 mm tube. If your two legs differ in size, split at the larger bore and reduce downstream with a PG reducer or a different-diameter fitting instead.
