Airtac PYB Y-Type Threaded Tee Fitting PYB1001D
The AirTAC Airtac PYB Y-Type Threaded Tee Fitting PYB1001D is a genuine branch y for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeBranch Y
- SeriesPYB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PYB Y-Type Threaded Tee Fitting PYB1001D
The PYB is AirTAC's branch Y one-touch fitting: a male-threaded Y body that divides one incoming tube line into two while its stem screws straight into a component or manifold port. This version, PYB1001D, grips Dia 10 mm soft nylon or polyurethane tube in both legs and carries a 1/8in PT male thread. Push each tube home and the internal chuck locks it; press the POM release ring against the body and the tube slides free, so branches can be re-routed without tools.
This is the resin-and-brass one-touch profile, not the metal line: 0 to 1.0 MPa (0-10 kgf/cm2) working pressure, usable down to -750 mmHg (10 Torr) vacuum, 1.5 MPa proof pressure and a -20 to +70 C range. The D suffix makes the whole Y body black - on this series the colour covers the body as well as the release button, unlike PC and POC where only the button changes - and the 1/8in thread arrives with sealant already applied.
Airtac PYB Y-Type Threaded Tee Fitting PYB1001D Technical Specifications
| Model | Airtac PYB Y-Type Threaded Tee Fitting PYB1001D |
|---|---|
| Type | Branch Y |
| Series | PYB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PYB Y-Type Threaded Tee Fitting PYB1001D
| PYB | Branch Y. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PYB Y-Type Threaded Tee Fitting PYB1001D Is Used
Twin-clamp drill jig feed
A single Dia 10 supply line teed off a machine manifold into this Y at the jig base, splitting to two compact cylinders that clamp a workpiece before the drill cycle starts.
Carton sealer blow-off pair
One Dia 10 drop from the packaging machine's FRL split by the Y into two short legs feeding blow-off nozzles either side of the flap folder, clearing dust before taping.
Dual-cup vacuum pick head
The -750 mmHg vacuum rating lets this Y split suction from one ejector to two cups lifting light plastic trays, with both legs running the same Dia 10 tube run.
Is the Airtac PYB Y-Type Threaded Tee Fitting PYB1001D the Right Part?
Within the PYB ladder at a 1/8in thread, the size below this one is Dia 8 (PYB801), a step down that suits lighter-duty branches and smaller tube clips. Dia 10 is where the 1/8in thread stops on the PYB range: if you need Dia 12 legs you move up to a 1/4in thread (PYB1202). Below 1/8in, the M5 option only carries Dia 4 and Dia 6, so it is not a like-for-like alternative. Whatever you order, tube OD must match the fitting exactly - a Dia 10 Y will not seal on 3/8in or 1/4in imperial tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PYB Y-Type Threaded Tee Fitting PYB1001D FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum capability down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. This SKU is a branch Y one-touch fitting for Dia 10 mm soft nylon or polyurethane tube with a 1/8in PT male thread, black body, and sealant pre-applied to the thread.
No. On the PYB range a 1/8in thread accepts tube from Dia 4 up to Dia 10 only, and Dia 10 is the top of that ladder. For Dia 12 legs you step up to the 1/4in threaded version, PYB1202. The chuck in each leg is sized to one tube OD, so undersized or oversized tube will not seal or hold.
