Airtac PYB Y-Type Threaded Tee Fitting PYB1002
The AirTAC Airtac PYB Y-Type Threaded Tee Fitting PYB1002 is a genuine branch y for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeBranch Y
- SeriesPYB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PYB Y-Type Threaded Tee Fitting PYB1002
The PYB1002 is an AirTAC PYB branch Y one-touch fitting: it screws into a 1/4in PT threaded port and divides that single air supply into two Dia 10 mm push-in tube lines running off at an inclined Y angle. Where a tee sends a branch out sideways at 90 degrees, the Y carries both lines off the port in a shallower spread, which is often the only way to route two runs out of one valve outlet inside a cramped manifold or guard.
This is the resin and brass one-touch family, rated 0-1.0 MPa (0-10 kgf/cm2), with a proof pressure of 1.5 MPa and a working temperature of -20 to +70 C. To connect, push the Dia 10 mm soft nylon or polyurethane tube straight in until it bottoms: the stainless spring gasket and POM chuck grip it immediately, and pressing the release ring frees it again. The 1/4in PT thread arrives from AirTAC with sealant already applied, so it seals without extra tape.
Airtac PYB Y-Type Threaded Tee Fitting PYB1002 Technical Specifications
| Model | Airtac PYB Y-Type Threaded Tee Fitting PYB1002 |
|---|---|
| Type | Branch Y |
| Series | PYB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PYB Y-Type Threaded Tee Fitting PYB1002
| PYB | Branch Y. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PYB Y-Type Threaded Tee Fitting PYB1002 Is Used
Twin-finger pneumatic gripper
One 1/4in PT valve outlet on a pick-and-place robot can feed both finger cylinders of a parallel gripper - the Y splits the supply into two Dia 10 mm lines that follow the wrist into the work envelope.
Manifold branch divider
On a packaging machine's air preparation manifold, a single 1/4in PT tap can be divided into two equal Dia 10 mm tube runs, one for the machine frame circuits and one for the tooling, without adding a second threaded port.
Textile machine jet supply
Looms and spinning frames run many small air jets from few ports; a PYB1002 at a 1/4in PT outlet pushes two 10 mm nylon lines out along the frame at a gentle spread instead of a hard right angle, easing routing along curved machine sections.
Is the Airtac PYB Y-Type Threaded Tee Fitting PYB1002 the Right Part?
This SKU sits mid-ladder on both axes. On the thread side, PYB1001 steps down to a 1/8in PT port and PYB1003 steps up to 3/8in - note that AirTAC caps the 1/8in PYB at Dia 10 mm tube, so this 1/4in part is the smallest thread that still opens the door to a Dia 12 upgrade later. On the tube side, PYB0802 branches into two 8 mm lines for lighter actuators and PYB1202 into two 12 mm lines for higher-demand circuits.
Match the 1/4in thread to a port actually tapped 1/4in PT; on reducers and reducers only do the sizes split, never here. And remember that the Dia 10 mm bore is fixed: a 10 mm fitting will not grip 5/16in or 3/8in hose, because the chuck and NBR O-ring are machined for exactly 10 mm outside diameter.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PYB Y-Type Threaded Tee Fitting PYB1002 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2); negative pressure -750 mmHg (10 Torr); proof pressure 1.5 MPa; operating temperature -20 to +70 C. The fitting accepts Dia 10 mm soft nylon or polyurethane tube on both push-in legs and mounts on a 1/4in PT male thread. It belongs to the resin and brass one-touch series, with a grey PBT body and brass stud, and the PT thread is supplied pre-coated with sealant.
No. Both push-in legs of a PYB branch Y accept the same tube OD as the code, here Dia 10 mm - the chuck, spring gasket and NBR O-ring are sized for exactly 10 mm and will not seal on 8 mm or 12 mm hose. If you need to step sizes down at the branch, use the PKD male reducer triple branch family instead, which combines a threaded port with a smaller branch tube diameter in one part.
