Airtac PYB Y-Type Threaded Tee Fitting PYB1003
The AirTAC Airtac PYB Y-Type Threaded Tee Fitting PYB1003 is a genuine branch y for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeBranch Y
- SeriesPYB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PYB Y-Type Threaded Tee Fitting PYB1003
The AirTAC PYB1003 is a male-threaded branch Y in the resin one-touch family: a 3/8in PT male thread feeds two Dia 10 mm push-in outlets arranged in a Y, so a single valve port can split into two tube runs without a separate tee and nipple. It is part of the grey resin and brass range with a PBT threaded body and brass stud.
Each outlet works like any one-touch fitting: push the soft nylon or polyurethane tube in until it bottoms, and the internal chuck grips it against the stainless spring gasket; press the release ring and the tube slides out again. Ratings are the resin profile - 0 to 1.0 MPa working pressure, -750 mmHg vacuum, 1.5 MPa proof pressure, -20 to +70 C. AirTAC applies sealant to the male thread before packing, so the 3/8in PT port seals straight into a tapped manifold or valve body without extra tape.
Airtac PYB Y-Type Threaded Tee Fitting PYB1003 Technical Specifications
| Model | Airtac PYB Y-Type Threaded Tee Fitting PYB1003 |
|---|---|
| Type | Branch Y |
| Series | PYB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PYB Y-Type Threaded Tee Fitting PYB1003
| PYB | Branch Y. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PYB Y-Type Threaded Tee Fitting PYB1003 Is Used
Twin suction cups on a pick-and-place arm
Split the single 3/8in output of a vacuum or air valve into two Dia 10 lines feeding paired suction cups, keeping the gripper plumbing to one fitting instead of a tee plus two nipples.
Small pneumatic press with dual feed lines
Take one supply branch off a manifold port and divide it to the two Dia 10 lines serving a compact air press or clamp cylinder set on a packaging line.
Manifold branch to two actuators
Where a control cabinet-adjacent manifold has one spare 3/8in tapped port, use the Y to run two Dia 10 polyurethane lines out to separate small actuators without extra threaded joints.
Is the Airtac PYB Y-Type Threaded Tee Fitting PYB1003 the Right Part?
On the 3/8in rung of the PYB ladder the neighbouring sizes are PYB0803 (Dia 8 tube) below and PYB1203 (Dia 12 tube) above. Stepping down to 8 mm trims the bore for lighter-flow circuits and shorter runs; stepping up to 12 mm suits longer branches or actuators that draw more air. Note that Dia 10 sits mid-ladder: the small M5 PYB versions only carry 4 and 6 mm tube, so a 10 mm branch Y always needs a 1/8in to 1/2in thread. If the branch point sits inside a machine frame where a rigid Y cannot swing into place, a PH-style universal elbow with swivelling thread may fit better. Match tube OD exactly - a Dia 10 outlet will not seal on 3/8in imperial tube, and a 3/8in thread will not seat in a 1/4in tapped port without a reducer.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PYB Y-Type Threaded Tee Fitting PYB1003 FAQ
Working pressure 0 to 1.0 MPa (0 to 10 kgf/cm2), negative pressure -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. The fitting is a Dia 10 mm tube branch Y with a 3/8in PT male thread, from the resin one-touch range with PBT body and brass stud. Applicable tubing is soft nylon or polyurethane.
On the 10 mm branch Y the published thread ladder is 1/8in (code 01), 1/4in (02), 3/8in (03) and 1/2in (04) - there is no M5 version at this tube size, since M5 PYB fittings only support Dia 4 and Dia 6 tube. If your port is a 1/4in tapped hole, order PYB1002 rather than adapting this 3/8in part.
