Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06A
$96.27
Regular price
$103.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAIF32X125-06A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The SAIF series valve-equipped cylinder is a derivative product integrating standard cylinders with valves, offering the following features:
1. Configured with 4M210 and 4M310 valves: 24M210 valves for 32/40/50mm bore sizes, 4M310 valves for 63/80/100mm bore specifications;
2. Enables direct one-to-one pneumatic control without requiring separate control valve installation;
3. Optimizes space utilization and reduces installation time, particularly suitable for decentralized applications in large-scale systems;
4. Multiple mounting accessory configurations available with simplified installation process.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAIF
Installation Protocol:
Mount using M5x0.8 mounting screws (max torque 3.5N·m). Maintain ≥15mm clearance around valve for heat dissipation.
Lubricate with ISO VG32 turbine oil if operating below -5℃. Perform monthly air filter drain checks.
1. Configured with 4M210 and 4M310 valves: 24M210 valves for 32/40/50mm bore sizes, 4M310 valves for 63/80/100mm bore specifications;
2. Enables direct one-to-one pneumatic control without requiring separate control valve installation;
3. Optimizes space utilization and reduces installation time, particularly suitable for decentralized applications in large-scale systems;
4. Multiple mounting accessory configurations available with simplified installation process.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAIF
AirTAC SAIF Standard Cylinder with Valve Type SAIF32X125-06A Technical Details
- Model Code Breakdown: SAIF32X125-06A = Series(SAIF) | Bore(32mm) | Stroke(125mm) | Port Size(06=PT1/4") | Valve Type(A)
- Bore Size: 32mm (ISO 6432 standard)
- Stroke Length: 125mm ±1mm tolerance
- Operating Pressure: 0.1-0.9 MPa (14.5-130.5 PSI)
- Cushioning: Adjustable air cushion at both ends
- Valve Type: Integrated 5/2-way single solenoid valve
- Voltage Options: DC24V (±10%) / AC110V (50/60Hz) / AC220V (50/60Hz)
- Port Thread: PT1/4 (BSPP) with NBR seals
- Ambient Temp Range: -10℃ to 70℃ (14°F to 158°F)
- Piston Speed: 50-800 mm/s (optimal range)
- Weight: 2.8kg (with valve and accessories)
- Dimensions:
- Total Length: 298mm (stroke extended)
- Body Diameter: 40mm (cylinder tube)
- Valve Block: 62mm(W) × 45mm(H)
- Mounting Center Distance: 25mm (front flange)
- Air Consumption: 1.5L/stroke at 0.5MPa
- Protection Class: IP67 (valve section), IP54 (cylinder)
This all-in-one pneumatic solution combines a ISO-standard cylinder with direct-mounted directional control valve, eliminating external tubing. The anodized aluminum construction features dual piston seals and wear-resistant guide rings. The integrated valve's low power coil (1.6W) enables continuous operation without overheating.
Industrial Implementation Scenarios:
- High-speed pick-and-place systems in electronics assembly lines
- Clamping mechanisms for CNC machine tooling
- Bottle cap pressing stations in beverage production
- Automated welding jig positioning systems
- Textile machinery thread tension control
Installation Protocol:
Mount using M5x0.8 mounting screws (max torque 3.5N·m). Maintain ≥15mm clearance around valve for heat dissipation.
Lubricate with ISO VG32 turbine oil if operating below -5℃. Perform monthly air filter drain checks.
⚠️ Critical Notice:
Always install lock nuts on adjustable cushions before pressurization.
Use shock absorbers when stroke-end impact velocity exceeds 500mm/s.
Maximum side load capacity: 35N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SAIF32X125-06A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M210-60-08 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
