Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 125mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke125 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilDC24V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B
The AirTAC SAIF32X125-06B is a double-acting ISO 15552 profile cylinder featuring an integrated 4M210-06 5/2 solenoid valve. This specific SKU is configured with a DC24V terminal electrical entry and a PT1/8 valve port. Delivering a Cv of 0.78 with a 14.0 mm2 orifice, the built-in valve eliminates the need for remote plumbing. The manifold connects to the cylinder via an O8 x O5 PU tube, while the cylinder itself features a PT1/8 port. Operating pressure is 0.15-0.8 MPa, as the valve limits the cylinder's 1.0 MPa rating. It generates 402N of push force at 0.5 MPa.
By default, the piston rod retracts when the coil is energised, but you can reconfigure it to extend-when-energised simply by repositioning the valve. This decentralized design requires only a single coil signal to drive the actuator, saving panel space and tubing. The DC24V coil consumes 3.0 W, features IP65 protection, and activates in 0.05 s or less. The 4M210 valve allows a maximum frequency of 5 cycles per second, and the cylinder speed ranges from 30-800 mm/s.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 125 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | DC24V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×125 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| B | Coil voltage DC24V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B Is Used
Decentralized Stations
Ideal for large machines with decentralized stations, eliminating long pneumatic tubing runs to a central panel.
Space-Tight Machines
Perfect for compact assemblies where mounting a separate valve and cylinder would exceed available envelope space.
Retrofitting Equipment
Simplifies upgrades on older machinery by requiring only a single DC24V electrical signal to control motion.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B the Right Choice?
Select this 32mm bore unit when your application requires 402N push force at 0.5 MPa. If you need higher thrust, stepping up to the 40mm bore yields 628N of push force at the same pressure. The SAIF32X125-06B is ideal for decentralized stations where running valve tubing is costly or space-prohibitive. It replaces a separate cylinder and remote valve with one self-switching unit. Remember that the 5/2 valve routes air but does not hold the load without live pressure; for position holding, consider the SAIL lock cylinder. To replace this unit, match the 32mm bore, 125mm stroke, 06 valve port, DC24V voltage, terminal entry, PT thread, and no magnet (-S).
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125-06B FAQ
The 32mm bore generates 402N of push force and 345N of pull force at 0.5 MPa. The integrated 4M210-06 valve provides an effective area of 14.0 mm2 (Cv 0.78).
The factory setting retracts the rod when the DC24V coil is energised. You can reconfigure it to extend-when-energised by repositioning the valve. No separate remote valve is needed.
