Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 125mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke125 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilAC24V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E
The AirTAC SAIF32X125S-06E is a double-acting ISO 15552 profile cylinder with a built-in 4M210-06 5/2 solenoid valve, delivering a Cv of 0.78 and a 14.0 mm2 effective area. Driven by an AC24V terminal entry coil drawing 3.5 VA, it activates in 0.05 s or less. Because the cylinder body rates to 1.0 MPa but the integrated valve operates at 0.15-0.8 MPa, the practical working range for this assembled unit is 0.15-0.8 MPa. In the 32 mm bore class, it generates 402 N of push force at 0.5 MPa. The carbon steel piston rod and -S magnet option enable precise position detection with AirTAC CMSE reed and DMSE electronic sensors.
This self-contained unit switches itself from one coil signal, eliminating the need for a remote valve and significantly reducing panel space and plumbing. The manifold connects to the cylinder via O8 x O5 PU tubing, and the valve port (1/8 inch) is distinct from the cylinder port. Factory-set to retract the rod when the coil is energised, the valve can be repositioned to extend on energisation. It is dimensionally interchangeable per ISO 15552 and runs at speeds of 30-800 mm/s without requiring lubrication.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 125 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC24V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×125 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| E | Coil voltage AC24V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E Is Used
Decentralized Assembly Stations
Ideal for large machines with multiple stations, using the built-in valve to eliminate long tubing runs back to a central panel.
Compact Electronics Handling
The 32 mm profile and AC24V terminal coil provide safe, space-saving actuation for delicate component positioning.
Retrofit Automation
Easily upgrade existing ISO 15552 fixtures by adding self-switching pneumatic control without extensive rewiring.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E the Right Choice?
Choose this 32 mm bore if your application requires around 402 N of push force at 0.5 MPa; stepping up to a 40 mm bore provides 628 N, while dropping to a smaller profile is not available in the SAIF range. The SAIF32X125S-06E is ideal for decentralized stations and space-tight machines where running separate valve tubing is costly or impractical. The AC24V terminal coil offers safe, low-voltage control with IP65 protection. For position feedback, the integrated -S magnet works seamlessly with CMSE and DMSE switches. Remember that the built-in 5/2 valve routes air and is not a lock; the air cushion only decelerates the piston near stroke ends. For load-holding requirements, consider the SAIL lock cylinder. When replacing, match the 32 mm bore, 125 mm stroke, 1/8 inch valve port, AC24V voltage, terminal entry, PT thread, and -S magnet.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06E FAQ
The 32 mm bore generates 402 N of push force and 345 N of pull force at 0.5 MPa. The integrated 4M210-06 valve has an effective area of 14.0 mm2 (Cv 0.78) and a maximum frequency of 5 cycles per second.
Yes. The factory setting retracts the piston rod when the AC24V coil is energised, but you can reconfigure it to extend-when-energised by repositioning the 5/2 valve on the manifold block. This allows directional control from a single coil signal without needing a separate remote valve.
