Airtac 2-Way Solenoid Valve 2W050-15-B
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W050-15-B Solenoid Valve Specifications
- Model: 2W050-15-B
- Type: 2-position 2-way direct acting (normally closed/NC)
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: BSPP (parallel thread)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max pressure: 1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Coil insulation class: Class B (130℃)
- Response time: ≤15ms (open), ≤10ms (close)
- Flow coefficient (Cv): 1.8
- Weight: 320g ±5% (including coil)
- Dimensions: 52mm(L) × 37mm(W) × 78mm(H)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Body material: Aluminum alloy (anodized)
- Temperature range: -5℃ to 80℃ (no freezing)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Protection rating: IP65 (coil), IP40 (valve body)
- Port orientation: Horizontal flow path
High-flow compact solenoid valve with manual override, featuring zero pressure start capability and optimized magnetic circuit design for energy efficiency. The hard-anodized body provides corrosion resistance in humid environments. Requires 5μm filtered compressed air with oil mist lubrication (ISO VG32 or equivalent).
- Industrial automation pneumatic circuits
- Packaging machine clamp control
- Textile machinery air flow switching
- Semiconductor manufacturing equipment
- Beverage filling line actuators
- Medical gas control systems
Installation note:
Mount in vibration-free environment with 20mm clearance around coil.
Use 0.3-0.5Nm torque for port connections. Lubricate seals with silicone grease
(non-petroleum based) during maintenance. For horizontal mounting, ensure
exhaust port faces downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | 2W050-15-B |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
