Airtac 2-Way Solenoid Valve 2W050-15-C
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W050-15-C Solenoid Valve Technical Details
- Model: 2W050-15-C
- Type: 2-position 2-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Flow coefficient (Cv): 0.15
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 295g ±5g (including coil)
- Dimensions: 60mm(L) × 50mm(W) × 75mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal compounds: NBR (standard), VITON optional
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Power consumption: 1.8W (DC), 2.5VA (AC)
- Protection class: IP65 (coil), IP40 (valve body)
- Port thread depth: 12mm (male threads)
High-speed electromagnetic valve with copper-free aluminum construction, optimized for compressed air systems requiring rapid cycling. Features manual override button (press-to-actuate) for system testing without power. Compatible with ISO 15407-1 standards, requires 5μm filtration (40μm for intermittent use).
- High-cycle pneumatic cylinders in assembly robots
- Vacuum generator control in pick-and-place systems
- Air blow cleaning circuits in CNC machinery
- Pressure regulation in textile machinery
- Modular valve systems for semiconductor handling
Installation guidelines:
Mount with inlet port (P) facing downward to prevent debris accumulation.
Use anti-vibration mounting brackets if operating frequency exceeds 5Hz.
Lubricate with ISO VG32 turbine oil if pneumatic system isn't pre-lubricated.
| Property | Property Value |
|---|---|
| sku | 2W050-15-C |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
