Airtac 2KSH Fluid Control Valve 2KSH03006AI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03006AI Technical Details
- Model: 2KSH03006AI
- Type: 3-position closed-center directional control valve (pneumatic)
- Port configuration: 5/3-way (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage variants: DC12V/24V ±10%, AC110V/220V ±10% (coil options)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Weight: 480g ±5% (including coil)
- Dimensions: 76mm(L) × 45mm(W) × 97mm(H)
- Body material: Anodized aluminum alloy (ISO 6351 compliant)
- Seal material: Fluorinated rubber (FKM) for high temp resistance
- Temperature range: -10℃ to 120℃ (with FKM seals)
- Lubrication: Pre-lubricated (maintenance-free for 10M cycles)
- Protection class: IP67 (coil), IP40 (valve body)
- Certification: RoHS, CE, ISO 13849-1 PLc
High-flow proportional control valve with closed-center spool design, engineered for precision pressure regulation in industrial automation. Features dual manual override buttons and LED status indicators (optional). Optimized for vacuum/pressure hybrid systems requiring mid-stroke position holding.
- Robotic gripper pressure sequencing in assembly lines
- Plastic injection molding machine clamp control
- CNC tool changer pneumatic circuits
- Semiconductor wafer handling vacuum systems
- Beverage filling station pressure balancing
Installation guidelines:
Mount horizontally with arrow aligned to flow direction. Use 50μm filtration
with auto-drain. For vertical mounting, add mechanical support bracket (sold separately).
Perform stroke test every 500K cycles.
| Property | Property Value |
|---|---|
| sku | 2KSH03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
