Airtac 2KSH Fluid Control Valve 2KSH03006BI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03006BI Technical Details
- Model: 2KSH03006BI
- Type: 2-position 3-way normally closed (direct acting)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 850 L/min (Cv=1.2)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (DC24V)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 320g ±5% (including coil)
- Dimensions: 76mm(L) × 32mm(W) × 40mm(H)
- Seal material: FKM fluorocarbon (standard), EPDM optional
- Temperature range: -5℃ to 80℃ (with FKM seals)
- Fluid compatibility: Air, inert gases, water (non-lubricated)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599-1 standard
High-speed fluid control valve with integrated manual override, featuring brass body with electroless nickel plating for corrosion resistance. Optimized flow path design reduces pressure drop by 18% compared to previous generation. Requires 5μm filtration (25μm for water applications). Compatible with vacuum systems when using optional EPDM seals.
- Coolant flow control in CNC machining centers
- Pneumatic cylinder sequencing in assembly lines
- Water circulation management in beverage dispensers
- Vacuum pump switching in packaging systems
- Hydraulic pilot control (low-pressure oil applications)
Installation guidelines:
Mount with flow direction arrow aligned. For liquid applications,
maintain minimum 2° downward tilt to prevent air pockets.
Use copper-free anti-seize compound on threads. Maximum tightening torque: 15N·m.
| Property | Property Value |
|---|---|
| sku | 2KSH03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
