Airtac 2KSH Fluid Control Valve 2KSH03006C
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH03006C Fluid Control Valve Technical Details
- Model: 2KSH03006C
- Type: 2-position 3-way normally closed (direct-acting)
- Port configuration: IN/OUT/EXHAUST
- Port thread size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.05–1.0 MPa
- Cv value: 0.18
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (open), ≤10ms (close)
- Seal material: HNBR (Hydrogenated Nitrile) for improved chemical resistance
- Body material: Anodized aluminum alloy
- Operating temperature: -10℃ to 80℃ (with silicone seals optional up to 150℃)
- Protection rating: IP67 (dustproof and waterproof)
- Weight: 220g ±5g
- Dimensions: 54mm(L) × 38mm(W) × 44mm(H) (excluding fittings)
- Port alignment: 18mm center-to-center spacing
- Mounting options: Direct piping or sub-base mounting (2KSH-MB03 compatible)
High-flow micro-valve with dual pressure balance structure for stable operation under fluctuating line pressures. Features gold-plated terminals for corrosion prevention and integrated surge protection diode. Designed for 5 million cycle durability with ≤1.5W low power consumption. Requires 25μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in packaging systems
- Medical gas distribution equipment
- Semiconductor wafer handling robots
- Food processing machinery (FDA-compliant seal options available)
Installation guidelines:
Maintain ≤3° deviation from horizontal mounting plane. Use anti-vibration
brackets in high-frequency applications (>15Hz). Lubricate with ISO VG32
turbine oil if operated in continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | 2KSH03006C |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
