Airtac 2KSH Fluid Control Valve 2KSH03006E
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH03006E Fluid Control Valve Technical Details
- Model: 2KSH03006E
- Type: 2-position, 3-way normally closed (direct-acting)
- Port configuration: 1/4" BSPP female threads (G1/4)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 0.8 L/min at 0.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (energize/de-energize)
- Weight: 298g ±5g
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H)
- Body material: Anodized aluminum alloy
- Seal material: FKM fluorocarbon rubber (standard), EPDM optional
- Fluid temperature range: -10℃ to 80℃ (NBR), -20℃ to 150℃ (FKM)
- Protection class: IP67 (dustproof and waterproof)
- Port alignment: ISO 5599-1 standard
High-precision proportional fluid control valve engineered for precise flow regulation in low-viscosity fluid systems. Features zero-leakage poppet design with TÜV-certified fail-safe operation. The hardened stainless steel shaft and dual-coil electromagnetic system ensure 500,000+ cycle durability. Compatible with air, inert gases, and non-corrosive hydraulic fluids (ISO VG32 or lighter). Requires 10μm filtration upstream.
- Precision dosing systems in pharmaceutical production
- Lubrication oil metering in CNC machinery
- Coolant flow control for laser cutting equipment
- Pneumatic brake modulation in AGVs
- Gas mixing systems for food packaging
Installation guidelines:
Mount in vibration-free environments with fluid flow direction matching body arrow indicator.
For horizontal installation, use support brackets (sold separately). Maintain minimum 20mm
clearance around solenoid for heat dissipation. Pre-charge system with 0.2MPa pressure
before initial activation.
| Property | Property Value |
|---|---|
| sku | 2KSH03006E |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
