Airtac 2KSH Fluid Control Valve 2KSH03008A
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008A Technical Details
- Model: 2KSH03008A
- Type: 3-position, 5-way closed center (Pilot-operated)
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–0.8 MPa
- Maximum flow rate: 1,000 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5% (including coil)
- Dimensions: 52mm(W) × 48mm(H) × 64mm(D)
- Seal material: HNBR (Hydrogenated Nitrile) for high oil resistance
- Temperature range: -20℃ to 80℃ (non-freezing)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (under rated conditions)
High-flow proportional control valve with closed-center functionality, featuring precision-machined spool mechanism for stable mid-position cutoff. The aluminum alloy body with hard anodizing treatment ensures corrosion resistance in humid environments. Integrated surge suppression protects against voltage spikes.
- Precision clamping force control in CNC fixtures
- Pneumatic cylinder mid-stroke holding systems
- Bottle filling machine pressure regulation
- Automated welding equipment actuator control
- Cleanroom robotics in semiconductor manufacturing
Installation guidelines:
Mount in vibration-free locations using M4 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance around exhaust ports (EA/EB) for proper venting.
Use ISO VG32 hydraulic oil or equivalent for lubrication if required.
| Property | Property Value |
|---|---|
| sku | 2KSH03008A |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
