Airtac 2KSH Fluid Control Valve 2KSH03008AI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008AI Technical Specifications
- Model: 2KSH03008AI
- Type: 3-position, 5-way closed center (Pilot-operated)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (including coil)
- Dimensions: 64mm(L) × 52mm(W) × 98mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: ≤2.5W (DC models), ≤3.5VA (AC models)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤50ms (exhaust to full flow)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with precision spool design, featuring dual-pressure balancing chambers for stable mid-position performance. The aluminum alloy body with hard anodizing resists chemical corrosion in humid environments. Integrated silencer reduces exhaust noise to ≤68dB(A).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changer positioning mechanisms
- Semiconductor wafer handling robotics
- Food processing pneumatic circuits (oil-free version available)
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15° maximum deviation from horizontal plane.
Use Loctite 542 thread sealant (not Teflon tape) for port connections.
| Property | Property Value |
|---|---|
| sku | 2KSH03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
