Airtac 2KSH Fluid Control Valve 2KSH03008BI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008BI Technical Details
- Model: 2KSH03008BI
- Type: 5/2-way single solenoid spring return
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (ANR)
- Actuation: Indirect pilot operated
- Seal material: NBR (Nitrile), optional FKM (Fluorocarbon)
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Response time: ≤15ms (at 0.5MPa)
- Protection class: IP67 (dust/water resistant)
- Weight: 280g ±5g
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with integrated silencer, featuring low power consumption (≤2.2W) and manual override capability. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Designed for ISO 15407-1 compliance with 10 million cycle durability rating.
- Pneumatic cylinder sequencing in assembly lines
- Material handling systems (clamping/rotating mechanisms)
- Textile machinery air flow control
- Semiconductor manufacturing equipment
- Automated packaging machine actuators
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (torque ≤0.8N·m).
Maintain 15mm clearance below valve for exhaust heat dissipation. Lubricate with ISO VG32
turbine oil if used in high-cycle applications (>500 operations/hour).
| Property | Property Value |
|---|---|
| sku | 2KSH03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
