Airtac 2KSH Fluid Control Valve 2KSH03008C
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008C Technical Details
- Model: 2KSH03008C
- Type: 3-position, 5-way closed center (pilot-operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5%
- Dimensions: 60mm(L) × 40mm(W) × 30mm(H) (excluding fittings)
- Seal material: HNBR rubber (hydrogenated nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Flow capacity: 750 L/min (ANR)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with center-block function, featuring corrosion-resistant aluminum alloy body and gold-plated pins for reliable signal transmission. The dual-pressure pilot design ensures stable switching even under fluctuating line pressures. Requires 5μm filtered dry air (dew point -20℃ below ambient).
- Automotive assembly line clamping systems
- Food processing pneumatic actuators (NSF compliant)
- Semiconductor wafer handling robots
- Plastic injection molding machine tool changers
- Cleanroom automation equipment
Installation guidelines:
Mount horizontally with pilot ports facing downward. Maintain minimum 15mm clearance around exhaust ports.
Use locknuts with 1.2-1.5Nm torque. Lubricate with ISO VG32 turbine oil if used in high-cycle applications (>500k operations/day).
| Property | Property Value |
|---|---|
| sku | 2KSH03008C |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
