Airtac 2KSH Fluid Control Valve 2KSH03008F
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008F Technical Specifications
- Model: 2KSH03008F (Full model code: 2KSH03008F-□S, □ indicates seal material code)
- Type: 2-position 3-way normally closed solenoid valve (Direct-acting)
- Port configuration: PT3/8 (BSPP thread) with NPT3/8 optional
- Effective flow rate: 1,200 L/min (Cv=1.8) at 0.5MPa
- Operating pressure range: 0.05–1.0 MPa (7–145 PSI)
- Voltage tolerance: ±10% for all models
- Voltage options:
- DC: 12V, 24V
- AC: 110V 50/60Hz, 220V 50/60Hz
- Surge-protected models available (S suffix)
- Weight: 680g ±2% (Excluding connectors)
- Dimensions: 62mm(W) × 45mm(H) × 105mm(L) (Port axis to coil face)
- Seal materials:
- Standard: HNBR (Hydrogenated Nitrile)
- Optional: FKM (Fluorocarbon) for chemical resistance
- Ambient temperature range: -20℃ to 60℃ (No freeze)
- Fluid temperature range: 0℃ to 60℃ (For water applications)
- Power consumption:
- DC models: 2.5W (Inrush 4.5W)
- AC models: 5.5VA (50Hz), 6.0VA (60Hz)
- Protection rating: IP67 (Coil assembly), IP54 (Valve body)
- Response time: ≤15ms (Energized), ≤20ms (De-energized)
- Port alignment: ISO 15407-1 compliant
High-flow proportional control valve with integrated manual override, featuring brass body with electroless nickel plating for corrosion resistance. The direct-acting design eliminates minimum pressure requirements, making it suitable for vacuum applications. Internal pilot structure reduces noise by 15dB compared to conventional valves. Compatible with air, inert gases, and water (requires FKM seals).
- Centralized lubrication systems in CNC machinery
- Coolant flow control in die-casting machines
- Pneumatic conveying line diverters
- Water treatment plant chemical dosing systems
- Beverage filling line pressure regulation
Installation guidelines:
Mount with flow direction arrow aligned. For liquid applications, install vertically with coil upward.
Use 20-30cm upstream strainer (40μm). Pipe connections must avoid torsional stress - maximum
allowable torque 35N·m. Allow 15mm clearance around coil for heat dissipation.
- Mechanical: 50 million cycles (ISO 15848 test standard)
- Coil insulation: Class F (155℃)
- Lubrication: Pre-lubricated for life (No maintenance required)
| Property | Property Value |
|---|---|
| sku | 2KSH03008F |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
