Airtac 2KWL Fluid Solenoid Valve 2KWL03006EI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03006EI Fluid Solenoid Valve Specifications
- Model: 2KWL03006EI
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 thread equivalent)
- Operating pressure: 0.02–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.2 (at 7 bar)
- Max operating frequency: 5Hz
- Seal material: FKM (Fluorocarbon Rubber) with SS316 core
- Temperature range: -10℃ to 150℃ (fluid dependent)
- Power consumption: 4.8W (DC24V), 5.5VA (AC)
- Protection rating: IP67 (submersible up to 1m for 30 mins)
- Weight: 420g ±5% (with coil)
- Dimensions: 78mm(L) × 48mm(W) × 42mm(H)
- Response time: ≤15ms (open/close)
- Port alignment: ISO 15407-1 compliant
High-pressure fluid control valve with enhanced chemical resistance, featuring dual-seal structure for leak-proof operation. The all-metal bonnet design withstands hydraulic shock up to 1.5MPa. Compatible with water, light oils, and air/neutral gases. Requires 10μm filtration for liquid applications.
- Hydraulic test bench pressure sequencing
- Industrial dishwasher chemical dosing systems
- Coolant control in CNC machining centers
- Reverse osmosis water treatment plants
- Food-grade lubricant dispensing systems
Installation note:
Mount with flow direction arrow aligned. For liquid use, install bypass circuit to prevent water hammer.
Minimum 500-hour burn-in test recommended for critical systems.
- Water (max 90℃)
- ISO VG32 hydraulic oil
- Ethylene glycol mixtures (≤50%)
- Non-corrosive gases (dew point -25℃)
Not compatible with ketones, esters, or chlorinated solvents.
| Property | Property Value |
|---|---|
| sku | 2KWL03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
