Airtac 2KWL Fluid Solenoid Valve 2KWL03006FI
$52.33
Regular price
$59.83
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2KWL03006FI
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**2KWL Fluid Solenoid Valve**
1. Direct-acting Normally Open (NO) 2-port 2-position solenoid valve with rapid and precise directional switching;
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
Installation guidelines:
Mount with flow arrow aligned to pipeline direction. Allow 20mm clearance
below valve for drain port access. Use PTFE tape on male threads - do not
overtighten (max 15N·m torque). Test cycle 5x before full operation.
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03006FI Fluid Solenoid Valve Technical Details
- Model: 2KWL03006FI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 380g ±5% (with coil)
- Dimensions: 85mm(L) × 50mm(W) × 100mm(H)
- Seal material: FKM (Viton®) for chemical resistance
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Fluid compatibility: Water, oil (ISO VG32-68), weak corrosive liquids
- Response time: ≤15ms (at 0.5MPa)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow solenoid valve engineered for precision fluid control in industrial systems. Features corrosion-resistant brass construction with epoxy-coated coil housing. Requires 25μm filtration upstream. Includes manual override and surge protection circuitry. Maximum viscosity: 50mm²/s.
Industrial Applications:
- Hydraulic lubrication systems in CNC machinery
- Beverage filling line liquid control
- Coolant circulation in die-casting equipment
- Chemical dosing systems (pH neutral solutions)
- Irrigation control in agricultural automation
Installation guidelines:
Mount with flow arrow aligned to pipeline direction. Allow 20mm clearance
below valve for drain port access. Use PTFE tape on male threads - do not
overtighten (max 15N·m torque). Test cycle 5x before full operation.
| Property | Property Value |
|---|---|
| sku | 2KWL03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
